CONNECTING A DPG
1 APM, 1 DPG configuration
0311385 Issue : April 1999
2-4
1 APM, 1 DPG configuration
READ
CAMERA
LAN
SN 388 APM
M / S
AUX
SU6
ACCB
POWER
(110/220 V)
SQC-Pro
CAMERA
DPG
RECORDER
ANALOG
Pilots
RADIO
LAN
BLASTER
SCSI
HCI
50
Ω
50
Ω
ACCB
to RADIO
POWER
Analog Pilots:
PILOTS 1 to 4 + Return Pilot + Return Sweep
(1)
(2)
(1)
RECORDER cable (part No. 1717075949)
(2)
ANALOG PILOT cable (part No. 1717075950)
