7
Startup
General startup instructions
Manual – MOVISAFE
®
CSB51A Safety Option
21
7 Startup
7.1 General startup instructions
INFORMATION
• The startup procedure of the standard functions of the basic device is described in
the respective operating instructions.
• Observe the information in chapter "Compatibility".
• The following chapters describe the additional startup procedure for the
MOVISAFE
®
CSB51A safety option and the drive safety functions.
• Note the prerequisites for installation and operation of MOVISUITE
®
.
• When starting up several similar devices with identical parameterization, the
devices can be parameterized via the "Import/Export" function. Note that you must
accept every single device to accomplish this.
7.2 Startup options
No drive safety function is approved in the delivery state of the basic device with
MOVISAFE
®
CSB51A safety option. A system error is issued. After acknowledging the
system error, the safety option is fully functional. The safety option permanently activ-
ates the STO function.
7.2.1 Variant 1: Startup with default parameterization
After the PROFIsafe protocol has been activated, the MOVISAFE
®
CSB51A safety op-
tion can be taken into operation with the default parameterization of the drive safety
functions.
Take into account the following constraints for this operating mode:
• The PROFIsafe protocol of the MOVISAFE
®
CSB51A safety option is activated us-
ing the "Assist CS.." parameterization tool.
For startup, perform the following steps:
1. The PROFIsafe protocol of the MOVISAFE
®
CSB51A safety option is activated us-
ing the "Assist CS.." parameterization tool.
2. Startup of the safe fieldbus and the higher-level F-PLC.
Ensure that the default parameterization of the MOVISAFE
®
CSB51A safety option
is active. To do so, check the following parameters (see following figure).
• The status of the parameterization of the safety option is "Accepted".
25931075/EN – 04/2019
