12
Technical data
General technical data
Manual – MOVISAFE
®
CSB51A Safety Option
46
12 Technical data
12.1 General technical data
Observe the technical data of the respective basic device.
12.2 General electrical data
The safety option is supplied with voltage by the basic device.
12.2.1 Power consumption of the safety option
Safety option Maximum current con-
sumption
Maximum power consumption
CSB51A 0.09A 2.1W
12.3 Characteristic safety values
Characteristic values pursuant to
EN62061/IEC61800-5-2 ENISO13849-1
Tested safety class/underlying
standards
SIL 3 PL e
Probability of dangerous failure per
hour (PFH
D
value)
3×10
-9
1/h
Mission time / service life 20 years, after which the component must be
replaced with a new one.
Proof test interval 20 years -
Safe state Value "0" for safe F‑DO_STO process value
(output disabled).
Drive safety function
• STO, SS1(c)
• Safe communication
25931075/EN – 04/2019
