Data exchange with higher-level controller
F-process output data
Manual – MOVISAFE
®
CSB51A Safety Option
33
9.3 F-process output data
Byte Bit Name Value Description
0 0 STO1 0 Activate STO.
1 Deactivate STO.
1 Reserve
2 Reserve
3 Reserve
4 Reserve
5 Reserve
6 Reserve
7 Fault ac-
knowledg-
ment
0 No acknowledgment.
1 Fault acknowledgment (0→1 edge).
1 0 Reserve
1 Reserve
2 Reserve
3 Reserve
4 Reserve
5 Reserve
6 Reserve
7 Reserve
2 0 Reserve
1 Reserve
2 SSX1 0 Activate SSx1.
1 Deactivate SSx1.
3 SSX2 0 Activate SSx2.
1 Deactivate SSx2.
4 Reserve
5 Reserve
6 Reserve
7 Reserve
9.3.1 Substitute values
In the F-controller, all bits described as "Reserve" must be set to "0".
