System Manual – MOVITRAC® B
53
2
UWS11A interface adapter option
Technical Data
2.10.4 Technical data
2.11 UWS11A interface adapter option
2.11.1 Part number
822 689 X
2.11.2 Description
The UWS11A option converts RS232 signals, for example from the PC, into RS485 sig-
nals. These RS485 signals can then be routed to the RS485 interface of the
MOVITRAC
®
.
The UWS11A option requires a DC 24 V voltage supply (I
max
= DC 50 mA).
2.11.3 RS232 interface
The connection between UWS11A and PC is made using a commercially available se-
rial interface cable (shielded!).
2.11.4 RS485 interface
Max. 32 MOVITRAC
®
units can be interconnected for communication [max. line length
200 m (656 ft)] via the RS485 interface of the UWS11A. Do not connect external termi-
nating resistors as dynamic terminating resistors are already installed.
Permitted cable cross-section: 1 core per terminal 0.20 – 2.5 mm
2
(AWG 24 - 12)
2 cores per terminal 0.20 – 1 mm
2
(AWG 24 – 17)
Part number 822 547 8
Input voltage DC 24 V ± 25%
Current consumption About 70 mA
Setpoint resolution 1%
Serial interface
1)
1) With integrated dynamic terminating resistor
RS485 for connecting max. 31 MOVITRAC
®
inverters (max. 200 m, (656 ft),
9600 baud)
Degree of protection IP65
Ambient temperature –15 °C to +60 °C
Dimensions 90 mm × 70 mm × 38 mm (3.5 in × 2.8 in × 1.5 in)
INFORMATION
The FSC11B/12B or FIO11B is required for connecting the UWS11A.
