58
System Manual – MOVITRAC® B
2
USB11A interface adapter
Technical Data
2.13 USB11A interface adapter
2.13.1 Part number
824 831 1
2.13.2 Description
Option USB11A can be used to connect a PC or laptop with a USB interface to the XT
slot of MOVITRAC
®
B. The USB11A interface adapter supports USB 1.1 and USB 2.0.
2.13.3 USB11A - PC
USB11A is connected to the PC using a commercially available, shielded USB connec-
tion cable type USB A-B.
2.13.4 RS485 interface
USB11B and MOVITRAC
®
B are connected using a serial interface cable with RJ10
connectors.
2.13.5 MOVITRAC
®
- USB11A
MOVITRAC
®
B and USB11A are connected using a serial interface cable with RJ10
connectors.
2.13.6 Scope of delivery
The scope of delivery for the USB11A option includes:
• USB11A interface adapter
• USB connection cable to connect USB11A - PC
• Serial interface cable with 2 RJ10 connectors to connect USB11A and
MOVITRAC
®
B
• CD-ROM with drivers and MOVITOOLS
®
MotionStudio engineering software
INFORMATION
The FSC11B/12B, FSE24B or FIO11B/21B is required for connecting the USB11A.
