Sewha SI 410 - Weighing mode 4. - Checker mode 2.

- 35 -
◆Weighing mode 4. - Checker mode 2. (500-04) - Simple comparison mode 2.
Relay output
Relay
Condition
Relay
Condition
OUT 1
Near zero < Current weight ≤ SP1 (ON)
OUT 5
SP4 < Current weight (ON)
OUT 2
SP1 < Current weight ≤ SP2 (ON)
OUT 6
Within near zero range
(Function HF29) (ON)
OUT 3
SP2 < Current weight ≤ SP3 (ON)
OUT 4
SP3 < Current weight ≤ SP4 (ON)
OUT 7
Cell-Error (ON)
※No Accumulation
