Shark BR Series User Manual

Shark BR 97-723 • REV. 11/06
OPERATOR’S MANUAL
PRESSURE WASHER
18
ITEM PART NO. DESCRIPTION QTY
38 Belts, See Specifications Pages
39 6-05109 Cable, Battery, 32" Red, 4 Gauge
(405039E, 455039E, 455034E
455037E) 1
40 6-051092 Cable, Battery, 36" Black, 4 Gauge
(405039E, 455039E, 455034E,
455037E) 1
41 2-30057 Valve, Shut-Off, 1/4 Turn (405039E,
455039E, 455034E, 455037E) 1
42 90-1007 Bolt, 5/16" x 1", NC HH (405039E,
455039E, 455034E, 455037E) 4
(404027,404029) 2
43 90-1010 Bolt, 5/16" x 1-3/4", NC HH
(404027, 404029) 4
90-1020 Bolt, 3/8" x 2", NC, HH (405039E,
455034E, 455037E, 455039E) 4
44 90-10343 Bolt, 10mm x 20mm, HH 4
45 90-1020 Bolt, 3/8" x 2" NC, HH 2
46 90-102746 Bolt, 1/2" x 5" NC HH Tap (404027,
404029, 405039E, 455039E,
455034E, 455037E) 1
47 90-18012 Screw, 1/4" x 5/8", Phil PH MS
(405039E, 455034E, 455037E,
455039E) 4
48 90-20041 Collar, 5/8" Bore Shaft 8
49 90-40181 Washer , Nylon Spacer, 0.656 x
1.25 x 0.65 THK 4
50 95-07101216/B Block, Unloader, 3/8" x 3/8"
Brass 1
51 95-07393125 Axle, 5/8" x 31.25" 2
52 95-07104028 Guard, Belt, Rear Steel 1
53 95-07162047 Assy, Weld, Battery Brkt, CW
Cage, Red (405039E, 455039E,
455037E) 1
95-07162048 Assy, Weld, Battery Brkt, CW
Cage, Black (455034E) 1
95-07162081 Holder, Nozzle (404027
404029) 1
54 95-07162054 Assy, Weld, Cage, CW Red
(BD, BR) 1
95-07162055 Assy. Weld, Cage, CW Black
(MP) 1
55 95-07162045 Guard, Belt, Front, CW Cage,
Black 1
56 95-07162071 Assy, Weld, Slider, CW Cage,
Red (404029, 405039E, 455037E,
455039E, 404027) 1
95-07162072 Assy, Weld, Slider, CW Cage,
Black (455034E) 1
57 90-1995 Screw, 1/4" x 1/2" BH SOC CS 7
58 90-2000 Nut, 1/4" ESNA, NC 4
EXPLODED VIEW PARTS LIST- LARGE
ITEM PART NO. DESCRIPTION QTY
59 90-4001 Washer, 5/16" FLAT, SAE (405039E,
455034E, 455037E, 455039E) 20
(404027,404029) 16
90-4002 Washer, 3/8" (404027, 404029) 2
(405039E, 455034E, 455037E,
455039E) 10
60 90-2001 Nut, 5/16" ESNA, NC (404027,
404029) 10
(405039E, 455034E, 455037E,
455039E) 12
90-2002 Nut, 3/8" ESNA (404027,
404029) 2
(405039E, 455034E, 455037E,
455039E) 6
61 90-100543 Screw, 5/16"-18 x 3/4" M PH
TRH (405039E, 455034E, 455037E,
455039E) 4
62 2-1046 Plug, 1/4" Countersunk (405039E,
455034E,455037E, 455039E) 1
63 90-400910 Washer, 7/16" Lock-Split Ring 4
64 2-01103 Grip, 1" Square Handle 2
65 2-10323 Tee, 1/2", Branch Male 1
66 95-07104828 Bracket, Brake Pad, Red
(BD, BR) 1
95-07164828 Bracket, Brake Pad, Black (MP) 1
67 95-07164829 Linkage, Brake, Black (MP) 1
95-07104829 Linkage, Brake, Red (BD, BR) 1
68 90-3096 Washer, 1/2" Flat 1
69 95-07162065 Handle, Break, CW Cage,
Red (BD, BR) 1
95-07162066 Handle, Break, CW Cage,
Black (MP) 1
70 90-100472 Bolt, Carriage, Zinc, 1/4"-20 x 1.0
PLT 4
71 2-9040 Clamp, Hose, .46-.54 ST
(405039E, 455039E, 455034E,
455037E) 2
72 90-4000 Washer, 1/4" Flat, SAE 12
73 90-40001 Washer, 1/4" FLAT, SAE, Black,
Zinc 5
74 90-4005 Washer, 5/8" Flat 8
75 1-100534 Valve, Safety Relief, 6000PSI
(405039E, 455039E, 455034E,
455037E) 1
76 2-0031 Elbow, 3/8" Street (405039E,
455039E, 455034E, 455037E) 1
77 2-0006 Nipple, 3/8" Hex Steel (405039E,
455037E, 455039E, 455034E) 1
78 2-0053 Elbow, 1/2" JIC, 3/8", 90° 1

Shark BR Series Specifications

General

Brand	Shark
Model	BR Series
Category	Pressure Washer
Language	English
