Shark BR Series User Manual

Shark BR 97-723 • REV. 11/06
17
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW PARTS LIST- LARGE
ITEM PART NO. DESCRIPTION QTY
1 10-02011 Label, This Tank For Gas Only
(405039E, 455037E, 455039E,
455034E) 1
2 10-02025A Label, “Hot/Caliente” w/Arrows 1
3 10-02029 Label, Danger Cool Engine
(455037E, 405039E, 455039E
455034E) 1
4 11-01011 Label, Warning Pictoral(Small) 1
5 11-013  Label, Logo, Belt Guard
(BR) 1
10-03014  Label, Logo, Belt Guard
(MP) 1
11-3227  Label, Logo, Belt Guard
(BD) 1
6 11-0316 Label, Instructions 1
7 10-03008 Label, Nozzle Identification 1
8 2-0051 Nipple, 1/2” JIC, 3/8” Pipe 1
9 2-0079 Swivel, 1/2" JIC Fem,
3/8" Male 1
10 2-010061 Bushing, Rubber, Nitrile (405039E,
455039E, 455034E, 455037E) 1
11 2-0103 Grommet, Rubber, Nozzle
Holder 5
12 2-011507 Tank, Encore 5 Gal. Tank
(405039E, 455039E, 455034E
455037E) 1
13 2-01167 Cap, Fuel Tank, Plastic (405039E,
455039E, 455034E, 455037E) 1
14 2-0117 Battery, Box (405039E, 455039E,
455034E, 455037E) 1
15 2-011700 Plate, Battery Box, Small, Polypro
(405039E, 455039E, 455034E,
455037E) 1
16 2-0051 Nipple 1/2" JIC x 3/8" Male
(404027, 404029) 1
2-00510 Nipple, 1/2" JIC x 3/8" Fem
(405039E, 455034E, 455037E,
455039E) 1
17 2-0155 Fastener, Ratchet, Black Nylon 2
18 2-1062 Elbow, 1/2" JIC x 1/2", 90°
(405039E, 455034E, 455037E
455039E) 2
(404027, 404029) 1
2-1060 Elbow, 1/2” JIC x 3/8”, 90°
(404027, 404029) 1
19 2-10942 Swivel, 1/2"MP x 3/4" GHF
w/Strainer 1
20 2-1105 Swivel, 1/2" JIC Fem, Push-On 2
21 2-1923 Strainer, 1/2" PA, Inline Plastic 1
ITEM PART NO. DESCRIPTION QTY
22 2-20022 Nipple, 3/8" Fem, 11,000 PSI”
(405039E, 455039E, 455034E,
455037E) 1
2-2007 Nipple, 3/8" x 3/8" NPT ST Male
(404027, 404029) 1
23 2-30082 Pump Protector, 1/2" PTP
(405039E, 455039E, 455034E,
455037E) 1
2-300816 Pump Protector, 3/8" (404027,
404029) 1
24 6-05137 Cable Tie Mount, Black (405039E,
455034E, 455037E) 2
25 2-9016 Clamp, Round, 0.56 I.D. (405039E,
455039E, 455034E, 455037E) 1
26 4-02047914 Hose, 3/8" x 14", 2 Wire,
Pressure Loop (405039E, 455034E
455037E, 455039E) 1
4-02047714 Hose, 3/8" x 1/4", 2 Wire Pressure
(404027, 404029) 1
27 4-02100000 Hose, 1/4", Push-On, Fuel Line
(405039E, 455039E, 455034E,
455037E) 57"
28 4-02110000 Hose, 1/2", Push-On 15"
29 4-0307 Wheel & Tire Cmpl, 6" 4
30 4-12803500 Nozzle, SACQMEG, 0003.5, Red
(405039E) 1
4-12803515 Nozzle, SAQCMEG 1503.5, Yellow
(405039E) 1
4-12803525 Nozzle, SAQCMEG, 2503.5,
Green (405039E) 1
4-12803540 Nozzle, SAQCMEG 4003.5, White
(405039E) 1
4-12804000 Nozzle, SAQCMEG 0004, Red
(404029, 404027,455039E,
455034E, 455037E) 1
4-12804015 Nozzle, SAQCMEG 1504, Yellow
(404029, 404027,455039E,
455034E, 455037E) 1
4-12804025 Nozzle, SAQCMEG 2504, Green
(404029, 404027,455039E,
455034E, 455037E) 1
4-12804040 Nozzle, SAQCMEG 4004, White
(404029, 404027,455039E,
455034E, 455037E) 1
4-16540 Nozzle COMPL, QCEM-6540,
Brass (404029, 455039E, 405039E,
455034E, 455037E) 1
31 Engine, See Specifications Pages
32 Pump, See Specifications Pages
33 Unloader, See Specifications Pages
34 Engine Pulley, See Specifications Pages
35 Pump Pulley, See Specifications Pages
36 Pump Bushing, See Specifications Pages
37 Engine Bushing, See Specifications Pages
