Shark BR 97-723 • REV. 11/06
21
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW PARTS LIST- SMALL
ITEM PART NO. DESCRIPTION QTY
1 10-02025A Label, "Hot/Caliente" w/Arrows
Warning 1
2 10-02029 Label, Danger Cool Engine 1
3 10-08017 Label, Intended For Outdoor Use 1
4 10-9999 Label, Clear Lexan,
2-1/4" x 4-1/2" 1
5 11-01011 Label, Warning, Pictoral, Small 1
6 11-0316 Label, Instructions 1
7 10-0623 Label, Belt Guard, MP (373534) 1
11-32289 Label, Belt Guard, BD (373539) 1
11-3229 Label, Belt Guard, BR (442537,
353237,373537,304037) 1
8 10-03008 Label, Nozzle Identification 1
9 2-0051 Nipple, 1/2" JIC, 3/8" Pipe 2
10 2-0053 Elbow, 1/2" JIC, 3/8", 90° 1
11 2-0079 Swivel, 1/2" JIC Fem, 3/8" Male 1
12 2-0103 Grommet, Rubber, Nozzle
Holder 5
13 2-01041 Pad, Soft Rubber, 50 Duro 2
14 2-01103 Grip, 1" Square, Handle 2
15 2-0117200 Belt Guard, CW 1
16 2-0155 Fastener, Ratchet, Black Nylon 2
17 2-10323 Elbow, 1/2" Street, Brass 1
18 2-1060 Elbow, 1/2" JIC x 3/8", 90° 1
19 2-1062 Elbow, 1/2" JIC x 1/2", 90° 1
20 2-10942 Swivel, 1/2" MP x 3/4" GHF
w/Strainer 1
21 2-1105 Swivel, 1/2" JIC Fem, Push-On 2
22 2-1923 Strainer, 1/2" PA, Inline Plastic 1
23 2-2007 Nipple, 3/8" x 3/8" NPT ST
Male 1
24 2-300816 Pump Protector, 3/8" PTP 1
25 4-02047720 Hose, 3/8" x 20", 2 Wire,
Pressure Loop 1
26 4-02110000 Hose, 1/2", Push-On 15"
27 4-0307 Wheel & Tire Assy, 6" Steel Rim
w/Tube 2
28 4-12804000 Nozzle, SAQCMEG 0004, Red
(373539,353237,373534,
373537) 1
4-12804015 Nozzle, SAQCMEG 1504, Yellow
(373539,353237,373534,
373537) 1
4-12804025 Nozzle, SAQCMEG 2504, Green
(373539,353237,373534,
373537) 1
4-12804040 Nozzle, SAQCMEG 4004, White
(373539,353237,373534,
373537) 1
ITEM PART NO. DESCRIPTION QTY
28 4-12805500 Nozzle, SAQCMEG 0005.5, Red
(442537) 1
4-12805515 Nozzle, SAQCMEG 1505.5, Yellow
(442537) 1
4-12805525 Nozzle, SAQCMEG 2505.5, Green
(442537) 1
4-12805540 Nozzle, SAQCMEG 4005.5, White
(442537) 1
4-12803000 Nozzle, SAQCMEG .0003, Red
(304037) 1
4-12803015 Nozzle, SAQCMEG 1503, Yellow
(304037) 1
4-12803025 Nozzle, SAQCMEG 2503, Green
(304037) 1
4-12803040 Nozzle, SAQCMEG 2504, White
(304037 1
4-16540 Nozzle, COMPL, QCEM-6540,
Brass (373539) 1
29 Engine, See Specifications Pages 24, 25
30 Pump, See Specifications Pages 24, 25
31 Unloader, See Specifications Pages 24, 25
32 Engine Pulley, See Specifications Pages 24, 25
33 Pump Pulley, See Specifications Pages 24, 25
34 Engine Bushing, See Specifications Pages 24, 25
35 Pump Bushing, See Specifications Pages 24, 25
36 Belt, See Specifications Pages 24, 25
37 90-1020 Bolt, 3/8" x 2" NCHH 6
38 90-1018 Bolt, 3/8" x 1-1/2", NC HH 2
39 90-102751 Bolt, 1/2" x 3-1/2", NC HH 1
40 90-10343 Bolt, 10mm x 20mm, HH 4
41 90-19710 Screw, 1/4" x 3/4" HH NC, Whiz 3
42 90-2002 Nut, 3/8" ESNA, NC 4
43 90-20041 Collar, 5/8" Bore Shaft 3010 4
44 90-3096 Washer, 1/2" Flat 1
45 90-4002 Washer, 3/8" Flat, SAE 8
46 90-4002 Washer, 3/8" SAE, Flat 2
47 90-40125 Washer, 3/8" x 1" 2
48 90-400910 Washer, 7/16", Lock Split Ring 4
49 90-40181 Washer, Nylon Spacer, 0.656" x
1.25" x 0.65" Thick 2
50
95-07101216/B
Block, Unloader, 3/8" x 3/8"
Brass 1
51 95-07104001 Slider, Pump/Belt Guard Mount,
Red (BD, BR) 1
95-07104033 Slider, Pump/Belt Guard Mount,
Black (MP) 1
52 95-07104723 Axle, 5/8" x 27.80 L 1
53 95-07162004 Assy, Weld, CW Cage, Small
Red (BD, BR) 1
95-07162005 Assy, Weld, CW Cage, Small
Black (MP) 1
To Next Page
