Shark BR Series User Manual

Shark BR 97-723 • REV. 11/06
25
PRESSURE WASHER
OPERATOR’S MANUAL
ITEM PART NO. DESCRIPTION QTY
35* 70-140012 Copper Spacer 3
36* 70-060103 O-Ring Ø1.78 x 7.66 3
37* 70-000904 Teflon Ring 3
38* Kit 70-05 Plunger (4035, 4035H) 3
Kit 70-06 Plunger (4030, 5030) 3
39* 70-140015 Copper Spacer 3
40 70-000301 Plunger Rod 3
41 70-010001 Connecting Rod 3
42 70-150001 Snap Ring 6
43 70-150201 Connecting Rod Pin 3
44 70-140102 Spring Washer 6
45 70-180105 Connecting Rod Screw 6
46 70-060009 Cover Gasket 1
47 70-020350 Crankcase Cover 1
48 70-060302 Gasket, G3/8 1
49 70-160117 Brass Plug 3/8 1
50 70-070001 Sight Glass G3/8 1
51 70-180112 Cover Screw 5
52 70-000929  Bach Ring 1/2" (4035H) 3
* Available in kit (See below)  Not Shown
REPAIR KIT
NUMBER
70-
261216
70-
260821
70-
260824 70-261210 70-260810 70-260825 70-261217 70-260822
70-
260823
70-
260007
70-
260027
Kit description
*Plunger
Seal
GM-4035
Plunger
Seal
GM-4030
GM-5030
Plunger
Seal
GM 3540
**Com-
plete Seal
Packing
GM-4035
Complete
Seal Pack-
ing
GM-4030
GM-5030
Complete
Seal Pack-
ing GM
3540
Plunger
GM-4035
GM-4035H
Plunger
GM-4030
GM-5030
Plunger
GM 3540
Complete
Valve
Plunger
Oil Seals
ITEM
NUMBERS
INCLUDED
4, 5, 7 4, 5, 7 4, 5, 7
3, 4, 5,
6, 7, 8
3, 4, 5,
6, 7, 8
3, 4, 5, 6,
7, 8
34, 35, 36,
37, 38, 39
34, 35, 36,
37, 38, 39
34, 35,
36, 37,
38, 39
12, 13, 14 3
NUMBER OF
CYLINDERS
KIT WILL
SERVICE
3 3 3 1 1 1 1 1 1 6 3
* For GM 4035H High Heat Packings, Use 70-261212 **For GM 4035H High Heat Packings, Use 70-261213
SM SERIES PUMP PARTS LIST
