AY-AP18CE AY-AP24CE
AH-AP18CE AH-AP24CE
AE-A18CE AE-A24CE
AU-A18CE AU-A24CE
3
ITEMS INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT
AH-AP18CE AU-A18CE AH-AP24CE AU-A24CE
Cooling capacity kW 5.1 6.7
Moisture removal Liters/h 1.6 2.2
Electrical data
Phase – Single
Rated frequency Hz 50
Rated voltage V 220 – 240
Rated current A 9.3 – 9.7 13.2 – 13.7
Rated input kW 2.01 – 2.15 2.68 – 2.84
Rated factor % 98 – 92 92 – 86
Compressor Type Hermetically sealed rotary type
Model PH33VPET 2JS464D3AA02
Oil charge 900cc [DIAMOND MS32(N-1)] 1130cc (
ATMOS M60 or SUNISO 4GD1D)
Refrigerant system Evaporator Louver fin and Grooved tube type
Condenser Louver fin and Grooved tube type
Control Capillary tube
Refrigerant volume 960g 1320g
De-lce system Micro computer controled reverse sysetm
Noise level High dB(A) 40 52 44 54
(at cooling) Med. dB(A) 36 – 39 –
Low dB(A) 34 – 37 –
Fan system
Drive Direct drive
Air flow quantity High m
3
/min. 15.3 48 18.1 46
(at cooling) Med. m
3
/min. 13.4 – 15.0 –
Low m
3
/min. 11.3 – 13.7 –
Fan Cross flow fan Propeller fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 1/2", 1/4" 5/8", 1/4"
Drain piping mm O.D ø 20
Others
Safety device Compressor: Internal protector Compressor: Internal protector
Fan motors: Thermal protector(Internal)
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 1040 (1155) 890 (1020) 1040 (1155) 890 (1020)
(Cartont dimensions)
Height mm 325 (300) 645 (735) 325 (300) 645 (735)
Depth mm 220 (385) 327 (398) 220 (385) 327 (398)
Net weight (Gross weight) kg 16 (21) 55 (59) 16 (21) 61 (65)
Note: The condition of star (
) marked item are ‘ISO5151:1994(E), condition T1’.
