AY-AP18CE AY-AP24CE
AH-AP18CEAH-AP24CE
AE-A18CE AE-A24CE
AU-A18CE AU-A24CE
46
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CABINET AND UNIT PARTS
1- 1 CMOT-A405JBKZ Fan moter sub assembly 1 BR
1- 2 PGUMSA088JBE0 Moter rubber 2 AL
1- 3 GWAK-A270JBFA Front panel 1 BA
1- 4 CHLD-A067JBK0 Bearing assembly 1 AL
1- 5 DCHS-A437JBKZ Cabinet sub assembly 1 BF
1- 6 NFANCA091JBEZ Cross flow fan 1 BD
1- 7 DSRA-A245JBKZ Drain pan sub assembly 1 BD
1- 8 CWAK-C200JBKZ Louver Frame assembly 1 BE
1- 9 MJNTPA082JBFA Louver link 3 AC
1-10 MLOV-A299JBFA Vertical louver 12 AC
1-11 MLOV-A297JBFA Horizontal louver 1 AK
1-12 QW-VZE168JBZZ Lead wire (for Louvermotor) 1 AH
1-13 LHLD-A197JBFP Louver holder 2 AC
1-14 NBRG-A026JBFA Louver bushing 1 AB
1-15 PCOV-A752JBFA Receving filter 1 AC
1-16 PHOS-A033JBEZ Drain hose 1 AP
1-17 PPACGA026JBEZ O ring 1 AC
1-18 PCOV-A750JBFZ Drain cover 1 AF
1-19 RMOT-A099JBEZ Louver motor 1 AT
1-20 CWAK-C201JBKZ Front panel assembly 1 BE
1-21 FCOV-A104JBFA Cover R 1 AE
1-22 FCOV-A105JBFA Cover L 1 AE
1-23 PCOV-A745JBRA Display cover 1 BB
1-24 HDEC-B145JBRA Display panel 1 AP
1-25 PFILMA163JBEA Air filter 2 AK
1-26 DHLD-A010JBKZ Tube holder assembly 1 AK
1-27 HPNL-A568JBFA Open panel 1 BA
1-28 PPLT-A278JBFZ Side cover L 1 AK
1-29 PPLT-A277JBFZ Side cover R 1 AH
1-30 PSHE-A200JBEZ Evaporator sheet 1 AD
1-31 LSPR-A021JBEZ Sheet spring 4 AE
1-32 LHLD-A550JBRA Display cover 1 BE
1-33 PGID-A103JBFA Frame guide 2 AU
1-34 DCOV-A204JBKZ Cluster cover ass’y 1 AE
1-35 LHLD-A536JBFA Holder 1 AM
1-36 LHLD-A277JBF0 Tube holder 1 AD
1-37 PCOV-A819JBEZ Cover 1 AA
1-38 PCOV-A820JBEZ Cover B 1 AB
1-39 LHLD-A548JBFA Holder 1 AM
1-40 LHLD-A549JBFA Holder 1 AM
1-41 QW-VZE167JBZZ Lead wire 1 AM
1-42 PFPFPC205JBEZ Filter insulator 2 AA
1-43 TSPC-E019JBRA Name label [AH-AP18CE] 1 AE
1-43 TSPC-E018JBRA Name label [AH-AP24CE] 1 AE
1-43 TSPC-E008JBRA Name label [AY-AP18CE] 1 AE
1-43 TSPC-E017JBRA Name label [AY-AP24CE] 1 AE
1-44 TLABCB554JBRZ Wiring diagram [AY-AP18CE] 1 AD
1-44 TLABCB560JBRZ Wiring diagram [AH-AP18CE] 1 AC
1-44 TLABCB559JBRZ Wiring diagram [AY-AP24CE] 1 AD
1-44 TLABCB561JBRZ Wiring diagram [AH-AP24CE] 1 AD
CONTROL BOX PARTS
2- 1 RTHM-A300JBE0 Thermistor 1 AN
2- 2 PBOX-A378JBFA Control box 1 AX
2- 3 PCOV-A744JBWZ Control box cover 1 AS
2- 4 LHLD-A500JBFZ Thermistor holder 1 AC
2- 5 PCOV-A300JBF0 Thermo holder cover 1 AB
2- 6 CPNL-A414JBKZ Control box cover 1 AK
2- 7 CKITTA002JBKZ High voltage unit (Plasma cluster unit) 1 BA
2- 8 LHLD-A537JBFA LED holder 1 AM
2- 9 LHLD-A542JBFA Holder 2 AM
2-10 DPWBFA251JBKZ Control board unit [AH-AP18CE] 1 BQ
2-10 DPWBFA250JBKZ Control board unit [AH-AP24CE] 1 BQ
2-10 DPWBFA242JBKZ Control board unit [AY-AP18CE] 1 BR
2-10 DPWBFA249JBKZ Control board unit [AY-AP24CE] 1 BR
2-11 QACC-A158JBE0 Power supply cord [AY-AP18CE/AH-AP18CE] 1 AT
2-12 QTANZA002JBZZ Terminal board (3pin) 1 AR
2-13 QTANZA002JBZZ Terminal board (3pin) [AH-AP18CE] 1 AN
2-13 QTANZA001JBZZ Terminal board (4pin) [AH-AP24CE] 1 AQ
2-13 QTANZA003JBZZ Terminal board (5pin) [AY-AP18CE] 1 AR
2-13 QTANZA004JBZZ Terminal board (6pin) [AY-AP24CE] 1 AT
2-14 FCOV-A106JBFA Receiving filters 1 AC
2-15 PCOV-A742JBFA LED holder 2 AC
