Sharp AH-AP18CE User Manual

AY-AP18CE AY-AP24CE
AH-AP18CE AH-AP24CE
AE-A18CE AE-A24CE
AU-A18CE AU-A24CE
33
Indoor side
Outdoor side
Temperature (˚C) Temperature (˚C)Relative humididity (%) Relative humididity (%)
27 47 35 40
Cooling
20 - 7 87
Heating
O.D. I.D. L
Capillary tube A
ø 3.2 ø 2.0 1200
Capillary tube C
(Upper row)
ø 2.7 ø 1.6 150
Capillary tube D
(Lower row)
ø 2.7 ø 1.6 244
O.D. I.D. L
Capillary tube A
ø 3.5 ø 2.2 400
Capillary tube B
ø 3.5 ø 2.2 700
Capillary tube C
(Upper row)
ø 2.7 ø 1.6 150
Capillary tube D
(Lower row)
ø 2.7 ø 1.6 244
For AY-AP18CE For AY-AP24CE
Cooling Cooling
NO. Condition
Model AY-P18CE
1
2
3
4
Service port pressure
93˚C 91˚C
40˚C 43˚C
11˚C 11˚C
9˚C 2˚C
0.55MPa 0.5MPa
AY-P24CE
Based on 'ISO 5151:1994(E),condition T1'
(at 220V refrigerant pipes length 7.5m)
Indoor side
Outdoor side
Temperature (˚C) Temperature (˚C)Relative humididity (%) Relative humididity (%)
27 47 35 40
Cooling
O.D. I.D. L
Capillary tube
ø 3.2 ø 2.0 1000
O.D. I.D. L
Capillary tube
ø 3.5 ø 2.2 450
For AH-AP18CE For AH-AP24CE
Cooling Heating
NO. Condition
Model AY-AP18CE
1
2
3
4
Service port pressure
94˚C 77˚C
41˚C 2˚C
11˚C 35˚C
7˚C -2˚C
0.58MPa 1.8MPa
Cooling Heating
AY-AP24CE
89˚C 88˚C
42˚C 2˚C
12˚C 38˚C
3˚C -2˚C
0.53MPa 2.1MPa
Based on 'ISO 5151:1994(E),condition T1'
(at 220V refrigerant pipes length 7.5m)
Cycle temperature and service port pressure
ISO condition
Dimension of Capillary tube
Cycle temperature and service port pressure
ISO condition
Dimension of Capillary tube
