AY-AP18CE AY-AP24CE
AH-AP18CE AH-AP24CE
AE-A18CE AE-A24CE
AU-A18CE AU-A24CE
9
Part Part Name Items Specifications
No. AY-AP18CE AY-AP24CE
1 Terminal Board Rating 300V 25A
2 Fan motor Rating 400V 2µF
Capacitor
3 Relay-1 Rating AC250V 20A –
(RY1) Coil Volt.; 12V
4 Relay-2 Rating AC250V 3A
(RY2, RY3, RY4) Coil Volt.; 12V
5 Printed Wiring Material Paper Base Phenolic Resin (UL 94V-0)
Board
6 Transformer Rating Pri 220 - 240VAC Sec. 19.0VDC
7 Fan motor Rating 220 - 240VAC 50Hz 41W 4-Pole
Type MLA999
Thermal
Protector
Cut off 135±10˚C
(Internal)
8 Power Supply Rating 3G 1.5mm
2
–
Cord H05VV-F –
9 Louver Motor Rating DC12V
Type MP24GA
Part Part Name Items Specifications
No. AE-A18CE AE-A24CE
1 Terminal Board Rating 300V 25A
2 Fan motor Rating 450V 3µF 450V 3µF
Capacitor
3 Running Rating 400V 50µF 400V 50µF
Capacitor
4 Compessor Rating AC220 - 240V 50Hz 1500W AC220 - 240V 50Hz 2200W
Type PH33VPET 2JS464D3AA02
5 Protector Manufacturer Ubukata Industries Co., Ltd. TEXAS INSTRUMENTS
Type UP3QF0302-T09 (INTERNAL) 3HM529-36V
Cutt off 130˚C 120˚C
6 Fan motor Rating
220 - 240VAC 50Hz 71W 6-Pole 220 - 240VAC 50Hz 75W 6-Pole
Type MLB002 MLB015
Thermal protector Cut off 135˚C±5˚C
(Internal)
7 Relay 5 Rating – AC250V 30A
for Compressor Coil volt: 200 -240VAC
ELECTRICAL PARTS
