AY-AP18CE AY-AP24CE
AH-AP18CE AH-AP24CE
AE-A18CE AE-A24CE
AU-A18CE AU-A24CE
47
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2-16 LHLD-A354JBFA Cord holder 1 AD
2-17 LHLD-A539JBFA Cord holder 1 AE
2-18 LHLD-A540JBFA Holder 1 AM
2-19 QSW-MA005JBZZ Switch 1 AG
2-20 QSW-MA147WRZZ Micro switch A 1 AG
2-21 RC-HZA421JBZZ Fan motor capacitor (C1) 1 AP
2-22 RH-IXA691JBZZ Microcomputer (IC1) 1 AU
2-23 RH-IZA149JBE0 Integrated circuit (IC2) 1 AE
2-24 RIC--A022BDE0 Integrated circuit (IC3) 1 AE
2-25 RIC--A025BDE0 Integrated circuit (IC4, IC5) 2 AE
2-26 RH-IZA140JBE0 Integrated circuit (IC6) 1 AE
2-27 VHIBR24C01A-6 Integrated circuit (IC8) 1 AF
2-28 RRMCUA001JBZZ Integrated circuit (IC101) 1 AK
2-29 RH-VXA002JBZZ Varistor (NR1) 1 AF
2-30 RTRN-A181JBE0 Current transformer (CT1) 1 AN
2-31 VHRS201D01/-6 Solid state relay (SSR1) 1 AK
2-32 RH-FZA015JBE0 Solid state relay (SSR2) 1 AH
2-33 RTRN-A287JBZZ Transformer (TR1) 1 AT
2-34 RRLYDA004JBZZ Relay (RY1) [AH-AP18CE, AY-AP18CE] 1 AG
2-35 RRLYDA008JBZZ Relay (RY4) [AH-AP24CE] 1 AH
2-35 RRLYDA008JBZZ Relay (RY4) [AY-AP18CE] 2 AH
2-35 RRLYDA008JBZZ Relay (RY4) [AY-AP24CE] 3 AH
2-36 QFS-GA027JBE0 Fuse (WPE1) 1 AD
CYCLE PARTS
3- 1 CPIPCA723JBKZ Tube assembly [AH-AP18CE, AY-AP18CE] 1 BA
3- 1 CPIPCA729JBKZ Tube assembly [AH-AP24CE, AY-AP24CE] 1 BA
3- 2 PSEN-A042JBKZ Flare nut assembly (1/4") 1 AL
3- 3 PSEN-A043JBKZ Flare nut assembly (3/8") 1 AD
3- 3 PSEN-A048JBKZ Flare nut assembly (1/2") [AH-AP24CE, AY-AP24CE] 1 AP
3- 4 PVLV-A222JBEZ Flare union (1/4") 1 AG
3- 5 PVLV-A223JBEZ Flare union (3/8") 1 AL
3- 5 PVLV-A238JBEZ Flare union (1/2") [AH-AP24CE, AY-AP24CE] 1 AM
3- 6 DEVA-A161JBKZ Evaporator sub assembly [AH-AP18CE, AY-AP18CE] 1 BW
3- 6 DEVA-A165JBKZ Evaporator sub assembly [AH-AP24CE, AY-AP24CE] 1 BW
ACCESSORY PARTS
4- 1 CRMC-A561JBEZ Remote control [AH-AP18CE, AY-AP24CE] 1 BA
4- 1 CRMC-A562JBEZ Remote control [AH-AP18CE, AH-AP24CE] 1 BA
4- 2 UBATUA027JBE0 Battery pack 1 AE
4- 3 LHLD-A535JBFA Cord holder
(for covering the terminal board of indoor unit)
1AE
4- 4 XTTSD40P20000 Tapping screw (for fixing the cord holder) 1 AA
4- 5 LX-NZA207JBEZ Special nut (for fixing long screw steadily) 9 AE
4- 6 LPFT-A029JBF0 Drain joint [AY-AP18CE, AY-AP24CE] 1 AD
4- 7 PPLTNA061JBWZ Mounting angle 1 AT
4- 8 XTTSD45P30000 Long screw 8 AA
4- 9 TINSEA293JBRZ Operation manual 1 AN
4-10 TINS-A703JBRZ Installation manual (Englisg,German,French,Spanish) 1 AE
4-11 TINS-A704JBRZ Installation manual (Italian,Portuguese,Greek,Russian) 1 AE
4-12 LX-BZA106JBE0 Special screw (for hanging remote controller) 1 AE
SCREWS
5- 1 LX-BZA075JBE0 Special screw (for earth) 1 AA
PACKING PARTS
6- 1 CPADBA047JBKZ Packing pad assembly 2 AN
6- 2 SPADBA162JBEZ Packing pad (sheet) 1 AL
6- 3 SPAKCA942JBEZ Packing case [AH-AP18CE] 1 AU
6- 3 SPAKCA941JBEZ Packing case [AH-AP24CE] 1 AU
6- 3 SPAKCA929JBEZ Packing case [AY-AP18CE] 1 AU
6- 3 SPAKCA940JBEZ Packing case [AY-AP24CE] 1 AU
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
