AY-AP18CE AY-AP24CE
AH-AP18CE AH-AP24CE
AE-A18CE AE-A24CE
AU-A18CE AU-A24CE
49
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CABINET AND UNIT PARTS
1- 1 LSUB-A024JBPZ Motor angle sub [AU-A18CE] 2 AP
1- 2 CMOTLB002JBEZ Fan motor [AU-A18CE] 1 BU
1- 2 CMOTLB015JBEZ Fan motor [AU-A24CE] 1 BS
1- 3 NFANPA108JBFA Propeller fan 1 BA
1- 4 LANGKA143JBPZ Motor angle [AU-A18CE] 1 AX
1- 4 LANGKA145JBPZ Motor angle [AU-A24CE] 1 AV
1- 5 PSKR-A241JBPZ Bulkhead 1 AT
1- 6 GPLTMA060JBTA Right side cover 1 AS
1- 7 CFTA-A275JBKZ Control cover assembly [AU-A18CE] 1 AW
1- 8 GCAB-A221JBTA Rear cabinet [AU-A18CE] 1 BE
1- 8 GCAB-A222JBTA Rear cabinet [AU-A24CE] 1 BE
1- 9 GCAB-A189JBTA Cabinet 1 BG
1-10 GGADFA028JBEA Fan guard 1 AZ
1-11 PSEL-C263JBEZ Bulkhead insulator A [AU-A18CE] 1 AE
1-11 PSEL-C280JBEZ Bulkhead insulator C [AU-A24CE] 1 AE
1-12 PSPF-A827JBEZ Compressor cover [AU-A18CE] 1 AS
1-12 PSPF-A834JBEZ Compressor cover [AU-A24CE] 1 AS
1-13 PSEL-C017JBEZ Cabinet seal 1 AC
1-14 TSPC-E021JBRZ Name label [AU-A18CE] 1 AE
1-14 TSPC-E022JBRZ Name label [AU-A24CE] 1 AD
1-15 TLABBA100JBRA SHARP badge 1 AE
1-16 CCHS-A777JBTA Base pan assembly [AU-A18CE] 1 BE
1-16 CCHS-A781JBTA Base pan assembly [AU-A24CE] 1 BF
1-17 PSEL-0625JBE0 Angle seal 1 AA
1-18 PSEL-C264JBEZ Bulkhead insulator B 1 AD
1-19 LBSHCA022JBF0 Bushing 1 AE
1-20 PFPFPC111JBEZ Corner insulator 1 AC
1-21 PSEL-B643JBE0 Insulator No. 9 1 AC
1-22 PSEL-C275JBEZ Insulator 1 AD
1-23 PSEL-C278JBEZ Insulator 1 AC
1-24 PSEL-C281JBEZ Cushion [AU-A18CE] 1 AC
1-24 PSEL-C282JBEZ Cushion [AU-A24CE] 1 AD
1-25 PSEL-C370JBEZ Insulator 1 AC
1-26 PSEL-C378JBEZ Insulator 1 AB
1-27 PSEL-C379JBEZ Insulator 1 AB
1-28 PSEL-C380JBEZ Insulator 1 AC
1-29 PSEL-A191JBE0 Condenser seal 1 AA
1-30 PFTA-A095JBFA Side cover 1 AR
CONTROL BOX PARTS
2- 1 RRLYJA088JBZZ Relay [AU-A24CE] 1 BA
2- 2 LHLD-A544JBFA Cord clamp holder 1 AG
2- 3 QW-IZA031JBZZ Compressor cord [AU-A18CE] 1 AR
2- 3 QW-IZA034JBZZ Compressor cord [AU-A24CE] 1 AR
2- 4 RC-HZA444JBZZ Running capacitor 1 AY
2- 5 RC-HZA404JBZZ Fan motor capacitor 1 AU
2- 6 QTANZA002JBZZ Terminal board [AU-A18CE] 1 AN
2- 6 QTANZA001JBZZ Terminal board [AU-A24CE] 1 AQ
2- 7 LHLD-A539JBFA Cord clamp 1 AE
2- 8 PBOX-A379JBWZ Control box 1 AR
2- 9 LBNDKA060JBW0 Capacitor clamp 1 AH
2-10 TLABCB563JBRZ Wiring diagram [AU-A18CE] 1 AD
2-10 TLABCB564JBRZ Wiring diagram [AU-A24CE] 1 AD
CYCLE PARTS
3- 1 PCMPRA355JBEZ Compressor [AU-A18CE] 1 CL
3- 1 PCMPRA299JBE0 Compressor [AU-A24CE] 1 CZ
3- 2 PCON-A479JBPZ Condenser [AU-A18CE] 1 CB
3- 2 PCON-A480JBPZ Condenser [AU-A24CE] 1 CC
3- 3 DVLV-A518JBKZ 2 Way valve assembly [AU-A18CE] 1 AV
3- 4 LX-NZA246JBEZ Flare nut 1 AN
3- 5 LX-NZA223JBEZ Valve cap 1 AY
3- 6 PCAP-A074JBFZ Bonnet 1 AF
3- 7 DVLV-A519JBKZ 3 Way valve assembly [AU-A18CE] 1 BA
3- 7 DVLV-A528JBKZ 3 Way valve assembly [AU-A24CE] 1 BF
3- 8 LX-NZA245JBEZ Flare nut [AU-A18CE] 1 AK
3- 8 LX-NZA258JBEZ Flare nut [AU-A24CE] 1 AM
3- 9 LX-NZA259JBEZ Service cap [AU-A24CE only] 1 AK
3-10 PCAP-A073JBEZ Bonnet [AU-A18CE] 1 AE
3-10 PCAP-A079JBEZ Bonnet [AU-A24CE] 1 AE
3-11 CCPY-A138JBKZ Capillary tube assembly [AU-A18CE] 1 AV
3-11 CCPY-A139JBKZ Capillary tube assembly [AU-A24CE] 1 BF
3-12 PCOV-A379JBE0 Terminal cover [AU-A18CE] 1 AF
3-12 PCOV-A010JBE0 Terminal cover [AU-A24CE] 1 AF
To Next Page
