Sharp AL2020 Service Manual

AL-2020/2035/2040/2050/2060 SIMULATION, TROUBLE CODES 10 - 10
24 05 Duplex counter clear [Function]
When [OK]/[START] key is pressed, the duplex counter value is cleared to 0, and "000,000" is
displayed on the LCD/display.
[Operation]
07 Drum counter clear [Function]
When [OK]/[START] key is pressed, the drum counter value is cleared to 0, and "000,000" is
displayed on the LCD/display.
[Operation]
08 Copy counter clear [Function]
When [OK]/[START] key is pressed, the copy counter value is cleared to 0, and "000,000" is dis-
played on the LCD/display.
[Operation]
09 Printer counter clear [Function]
When [OK]/[START] key is pressed, the printer counter value is cleared to 0, and "000,000" is
displayed on the LCD/display.
[Operation]
10 FAX counter clear
(AL-2060 only)
[Function]
When [OK]/[START] key is pressed, the FAX count value is set to 0 and "000,000" is displayed
on the LCD.
[Operation]
13 Scanner counter clear [Function]
When [OK]/[START] key is pressed, the scanner counter value is cleared to 0, and "000,000" is
displayed on the LCD/display.
[Operation]
14 SPF/RSPF JAM total
counter clear
(excluding AL-2020)
[Function]
When [OK]/[START] key is pressed, the SPF/RSPF JAM total counter value is cleared to 0, and
"000,000" is displayed on the LCD/display.
[Operation]
Main
code
Sub
code
Contents Details of function/operation
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-16.
24-05 DPLX CLR.
CLEARED 000,000
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
24-07 DRUM CLR.
CLEARED 000,000
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
24-08 COPIES CLR.
CLEARED 000,000
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
24-09 PRT.CLR.
CLEARED 000,000
1) Initial display
24-10 FAX CLR.
CLEARED 000,000
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
24-13 SCAN CLR.
CLEARED 000,000
AL-2050/2060
1) Initial display
AL-2035/2040
The operation is similar to simulation 22-04.
24-14 S JAM TTL CLR.
CLEARED 000,000
