AL-2020/2035/2040/2050/2060 SIMULATION, TROUBLE CODES 10 - 9
22 17 Copy counter display [Function]
The copy counter is displayed.
[Operation]
18 Printer counter display [Function]
The printer counter is displayed.
[Operation]
19 Scanner mode counter
display
[Function]
The scanner mode counter is displayed.
[Operation]
21 Scanner counter display [Function]
The scanner counter is displayed.
[Operation]
22 SPF/RSPF JAM counter
display (excluding AL-2020)
[Function]
The SPF/RSPF JAM counter is displayed.
[Operation]
24 01 JAM total counter clear [Function]
When [OK]/[START] key is pressed, the JAM total counter is cleared to 0 and "000,000" is dis-
played on the LCD/display.
[Operation]
04 SPF/RSPF counter clear
(excluding AL-2020)
[Function]
When [OK]/[START] key is pressed, the SPF/RSPF counter value is cleared to 0 and "000,000"
is displayed on the LCD/display.
[Operation]
Main
code
Sub
code
Contents Details of function/operation
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
22-17 COPIES CNT
***,***
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
22-18 PRT.CNT
***,***
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-16.
22-19 S-MODE CNT
***,***
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
22-21 SCAN CNT
***,***
AL-2050/2060
1) Initial display
AL-2035/2040
The operation is similar to simulation 22-04.
22-22 S JAM CNT
***,***
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
24-01 JAM TTL CLR.
CLEARED 000,000
AL-2050/2060
1) Initial display
AL-2035/2040
The operation is similar to simulation 22-04.
24-04 SPF CLR.
CLEARED 000,000
