Sharp AL2020 Service Manual

AL-2020/2035/2040/2050/2060 SIMULATION, TROUBLE CODES 10 - 8
22 08 SPF/RSPF counter display
(excluding AL-2020)
[Function]
The SPF/RSPF counter is displayed.
[Operation]
11 FAX-related counter display
(AL-2060 only)
[Function]
The FAX-related counter is displayed.
[Operation]
12 Drum counter display [Function]
The drum counter is displayed.
[Operation]
14 ROM version display [Function]
The P-ROM version is displayed.
Press [ ] [ ] key (or [Numeric] key or [ ] [ ] key for the AL-2050/2060) to switch the dis-
play version.
[Operation]
16 Duplex counter display [Function]
The duplex counter is displayed.
[Operation]
Main
code
Sub
code
Contents Details of function/operation
AL-2050/2060
1) Initial display
AL-2035/2040
The operation is similar to simulation 22-04.
22-08 SPF CNT
***,***
1) Initial display
∗ [Clear] key: FAX control is terminated.
2) Select 1
("xxx,xxx" is the current value.)
∗ [Clear] key: Returns to "1) Initial display".
2) Select 2
("xxxx: xxx. xx" is the current value.)
∗ [Clear] key: Returns to "1) Initial display".
SELECT COUNTER
1:PAGE 2:TIME
SEND PAGE:xxx,xxx
RECV PAGE:xxx,xxx
TX TIME:xxxx:xx.xx
RX TIME:xxxx:xx.xx
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The operation is similar to simulation 22-04.
22-12 DRUM CNT
***,***
Code number Version Display item
0 Main unit Program MAIN PROG.
1 F-IMC Program F-IMC PROG.
2 LCD DATA LCD DATA
AL-2050/2060
1) Initial display
2) [Numeric] key or [ ] key
2) [Numeric] key or [ ] key
AL-2020/2035/2040
The operation is similar to simulation 22-04.
22-14 ROM VER.
MAIN PROG. 00.00
22-14 ROM VER.
F-IMC PROG. 00.00
22-14 ROM VER.
LCD DATA 00.00
AL-2050/2060
1) Initial display
AL-2020/2035/2040
The count value is displayed in 3 digits X 2
times repeatedly.
<Display example: 12345>
22-16 DPLX CNT
***,***
012 → Blank → 345 → Blank → 012
0.7s 0.3s 0.7s 1.0s 0.7s
