Sharp AL2020 Service Manual

AL-2020/2035/2040/2050/2060 SIMULATION, TROUBLE CODES 10 - 37
66 18 DTMF signal send
(Soft SW set value)
(AL-2060 only)
[Function]
Use to set the DTMF signal send (Soft SW set value).
[Operation]
21 FAX information print
(AL-2060 only)
[Function]
Use to print the FAX information.
[Operation]
24 FAST SRAM clear
(AL-2060 only)
[Function]
Use to clear the FAST SRAM.
[Operation]
30 TEL/LIU status change
check (AL-2060 only)
[Function]
Use to check the TEL/LIU status change.
[Operation]
Main
code
Sub
code
Contents Details of function/operation
1) Initial display
∗ [Clear] key: FAX control is terminated.
2) [Numeric] key: Input
The content selected with signal send
level selection is set inside.
3) Communication is started after setting the
signal send level.
∗ [Clear] key: Returns to "1) Initial display".
INPUT DIAL #
SENDING SIGNAL SSW
PRESS CLEAR TO STOP
1) Initial display
2) [ ] [ ] key or after 2sec
Every time when [ ] key is pressed, the second line is changed in the sequence of 1 → 2
→ 3 → 1.
When [ ] key is pressed, the sequence is reversed.
∗ [Clear] key: FAX control is terminated.
3) [OK] key
• When print is allowed
After completion of printing,
FAX control is terminated.
• When print is inhibited
After 2sec, FAX control is
terminated.
SELECT REPORT (1-3)
PRESS ←, →
SELECT REPORT (1-3)
1:USER SW. LIST
SELECT REPORT (1-3)
2:SOFT SW. LIST
SELECT REPORT (1-3)
3:PROTOCOL
PRINT STORED CAN NOT PRINT
1) Initial display 2) After completion of clearing
After 2sec, FAX control is terminated.
CLEAR FAST SRAM
CLEARED
1) Initial display
↑
The display is switched every 2sec.
↓
∗ [Clear] key: FAX control is terminated.
HS2 :xxx HS1 :xxx
RHS :xxx EXHS:xxx
CHECKING
PRESS CLEAR TO STOP
