AL-2020/2035/2040/2050/2060 FAX SOFT SWITCH 12 - 21
S
W
103
1 Scan effective image area
sub scan lead edge image
loss (OC)
Binary input
96 lines
0
2 Bit No.
Set range
1234
0 to 240 line
16 lines interval
1
3 1
4 0
5 Scan effective image area
sub scan rear edge image
loss (OC)
Binary input
144 lines
1
6 Bit No.
Set range
5678
0 to 240 line
16 lines interval
0
7 0
8 1
S
W
104
1 Scan effective image area
main scan left edge image
loss (RSPF back surface)
Binary input
96 dots
0
2 Bit No.
Set range
1234
0 to 360 dots
in the interval of 24 dots
1
3 0
4 0
5 Scan effective image area
main scan right edge
image loss (RSPF back
surface)
Binary input
96 dots
0
6 Bit No.
Set range
5678
0 to 360 dots
in the interval of 24 dots
1
7 0
8 0
S
W
105
1 Scan magnification ratio
adjustment (OC main
scan) flag
1: – 0: +
+0
2 Scan magnification ratio
adjustment (OC main
scan)
Binary input
0%
0
3 Bit No.
Set range
2345678
0 to ±12.7%
0.1% interval
0
4 0
5 0
6 0
7 0
8 0
S
W
106
1 Scan magnification ratio
adjustment (OC sub scan)
flag
1: – 0: +
+0
2 Scan magnification ratio
adjustment (OC sub scan)
Binary input
0%
0
3 Bit No.
Set range
2345678
0 to ±12.7%
0.1% interval
0
4 0
5 0
6 0
7 0
8 0
S
W
107
1 Scan magnification ratio
adjustment (RSPF back
surface main scan) flag
1: – 0: +
+0
2 Scan magnification ratio
adjustment (RSPF back
surface main scan)
Binary input
0%
0
3 Bit No.
Set range
2345678
0 to ±12.7%
0.1% interval
0
4 0
5 0
6 0
7 0
8 0
S
W
108
1 Scan magnification ratio
adjustment (RSPF back
surface sub scan) flag
1: – 0: +
+0
2 Scan magnification ratio
adjustment (RSPF back
surface sub scan)
Binary input
0%
0
3 Bit No.
Set range
2345678
0 to ±12.7%
0.1% interval
0
4 0
5 0
6 0
7 0
8 0
SW
NO.
Data
No.
Item Switch selection and contents of functions Initial value Remark
