9
Preparation
Simple operations for watching a TV programme
Basic connection
Connecting to an antenna
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for coaxial cable.
Standard DIN45325 plug (IEC169-2)
75-ohm coaxial cable (round cable)
Room antenna terminal
(75-ohm type)
Antenna cable
(commercially available)
To antenna
terminal
Connecting to the AC outlet
Rear view
AC outlet
NOTE
• Always turn off the power of the TV when connecting the AC cord.
• Disconnect the AC cord from the AC outlet if the TV will not be used for a long period of time.
Antenna input terminal
(ANALOGUE)
Antenna input terminal (DTV)
42PD7X_en_a.indd 942PD7X_en_a.indd 9 2007/01/12 15:45:192007/01/12 15:45:19
To Next Page
