Sharp AQUOS LC-42PD7X

13
Part names
TV (Rear)
RS-232C terminal
INPUT 3 (HDMI)
terminals
INPUT 4 (AUDIO)
terminals
MONITOR OUTPUT
terminals
INPUT 2 terminals
INPUT 1 terminals
Antenna input terminal
(ANALOGUE)
AC INPUT terminal
SERVICE ONLY terminal*
*Usually do not connect anything to this terminal as it is reserved only for service personnel.
INPUT 4 (HDMI)
terminals
INPUT 5 terminals
DIGITAL AUDIO OUTPUT
terminal (To optical digital input
of external audio devices)
Antenna input terminal (DTV)
