14
Preparation
Connecting a STB (Satellite, Cable, etc.)
You can use the INPUT 1/INPUT 2/ INPUT 3 (HDMI) or INPUT 4/INPUT 6 terminals when connecting to a STB
(Satellite, Cable, etc.) and other audiovisual equipment.
When using HDMI cable
(commercially available)
When using component cable
(commercially available)
R – AUDIO – L
Y
P
B
(CB)
P
R
(CR)
Connecting a PC
You can use the INPUT 7 (PC) terminal when connecting to a PC.
STB
(Set Top Box)
PC
STB (Set Top Box)
LC46LE700X_EN.indb 14LC46LE700X_EN.indb 14 11/23/2009 1:00:25 PM11/23/2009 1:00:25 PM
To Next Page
