6
Preparation
Attaching the stand
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work, spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Screw driver
(not supplied)
Long screw
1
Confi rm the 8 screws supplied with the TV.
Short screws (
g
4)
(used in step 3)
Long screws (
g
4)
(used in step 2)
2
Attach the supporting post for the stand unit
onto the base as shown below.
3
1
Insert the stand into the openings on the
bottom of the TV.
2
Insert and tighten the 4 short screws into
the 4 holes on the rear of the TV.
NOTE
• To detach the stand, perform the steps in reverse order.
Screw driver
(not supplied)
Short screw
Soft cushion
