7
Preparation
Part names
TV (Front/Side)
*OPC: Optical Picture Control (See page 34.)
** See page 16 for the TV status indicator.
*** Blue illumination Emblem (See page 17.)
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
• The illustration used throughout this manual are based on LC-46LE700X.
Volume up (
e
)/down (
f
) buttons
Channel up (
r
)/down (
s
) buttons
POWER (On/Off) button
TV/VIDEO button
MENU button
OPC indicator* OPC sensor
Remote control sensor
POWER indicator**
Blue illumination Emblem***
LC46LE700X_EN.indb 7LC46LE700X_EN.indb 7 11/23/2009 1:00:25 PM11/23/2009 1:00:25 PM
