AR-5127 DISASSEMBLY, ASSEMBLY AND MAINTENANCE 10 - 7
Removal*Raise the shutter arm before its removal.
Installation*Install so that the boss of the lever arm comes into the rib
of the shutter arm.
Installation*Install so that the cam transmit arm (1) comes under the
roller arm (2).
b. Separation sheet
∗
Slightly apply grease GP501MR (UKOG-0012QSZZ) around the
axis. One rice grain for each.
1)
2)
2)
1)
2)
1)
2)
No. Part name
Service
items
Cycle Remarks
1 Pickup roller (Multi
bypass tray)
Check
50k
Changing criteria
for parts: 50k
2 Separation roller (Multi
bypass tray)
Check
50k
Changing criteria
for parts: 50k
3 Separation sheet (Multi
bypass tray)
Check
50k
Changing criteria
for parts: 50k
L
C
K
T
O
K
O
2)
3)
1)
4)
5)
2
1
1)
2)
3)
3
