AR-5618S DISASSEMBLY AND ASSEMBLY 10-8
D. Paper exit sensor / duplex sensor
(A) Exit sensor
(B) Duplex sensor
E. Transport roller
F. Paper exit roller
Assembly: Insert the spring pin so that the waveform (A) of the spring
pin faces in the longitudinal direction of the paper exit
drive gear long hole (B).<R>Be sure to insert two ribs (C)
into the groove (D).
(A)
(B)
1
(1)
(2)
(1)
(1)
(2)
(3)
(4)
(5)
(3)
(1)
(1)
(2)
(A)
(B)
(D)
(C)
(C)
(1)
(1)
(2)
(2)
(2)
(3)
：'11/Jul/22
