Sharp CV-P10PR User Manual

GB-8
HOW TO USE THE REMOTE CONTROL
Point the remote control toward the Signal re-
ceiver and press the desired button. The unit
generates a beep when it receives the signal.
• Make sure nothing, such as curtains, blocks the
signal receiver window.
• The signal effective distance is 7 m.
CAUTION:
• Do not expose the receiver window to direct sun-
light. This may adversely affect its operation.
• Use of certain uorescent lamp in the same room
may interfere with transmission of the signal.
• Do not leave the remote control in direct sunlight
or near a heater. Protect the remote control from
moisture and shock.
To prevent the remote control from being
misplaced,hookittotheunitwhennotin
use.
When attached, to remove the remote control from
the unit, lift the remote control up slightly and pull it
out.
Remote control hook
LOADING BATTERIES
1
Remove the battery cover.
2
Insert two batteries.
(AAA(R03))
• Make sure the (+) and (-) polarities are cor-
rectly aligned.
• Lines will appear on the display when bat-
teries are properly installed.
3
Reattach the battery cover.
4
Press the RESET button using a thin
pointed implement.
NOTES:
• The battery life is approximately 1 year in normal
use.
• When replacing the batteries, always change
both and use the same type.
• If you will not be using the unit for a long time, re-
move the batteries from the remote control.
Battery cover
USING THE REMOTE CONTROL
01_CV-P10PR_OM_EN.indd 8 14/08/29 16:42

Sharp CV-P10PR Specifications

General

Type	Monobloc mobile air conditioner
Hose length	1.5 m
Noise level	52 dB
Hose diameter	140 mm
Ionic function	Yes
Number of speeds	3
Airflow (high speed)	34.8 m³/h
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1 l/h
Timer duration (maximum)	12 h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling capacity in watts (max)	2500 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Connected load	960 W
AC input voltage	220-240 V
AC input frequency	50 Hz
Annual energy consumption (cooling)	- kWh
Product color	Silver

Weight and Dimensions

Depth	450 mm
Width	500 mm
Height	830 mm
Weight	42000 g
