Sharp CV-P10PR User Manual

GB-6
Installation of the exhaust hose
1
Attach the insect guard net to the
window adapter.
Push the insect guard net rmly to en-
sure that four projections on the window
adapter t into the four holes on it.
2
Attach the window adapter to the
exhaust hose.
Extend one end of the exhaust hose and
insert it into the window adapter, and
turn it (approx. three times) until it stops.
Make sure they are securely attached.
3
Attach the rain guards to the in-
sect guard net.
Insert all three projections on each rain
guard into the holes in the insect guard
net.
Side “A” will now be at the top, as indi-
cated in the diagram.
INSTALLATION AND REMOVAL OF EXHAUST HOSE
Exhaust hose
Window adapter
Extend
Hole
Projection
Insect guard net
Rain guard
"A"
Insect guard net
Hole
Hole
Projection
Insect guard net
Rain guard
"A"
Horizontally placed
Vertically placed
01_CV-P10PR_OM_EN.indd 6 14/08/29 16:42

Sharp CV-P10PR Specifications

General

Type	Monobloc mobile air conditioner
Hose length	1.5 m
Noise level	52 dB
Hose diameter	140 mm
Ionic function	Yes
Number of speeds	3
Airflow (high speed)	34.8 m³/h
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1 l/h
Timer duration (maximum)	12 h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling capacity in watts (max)	2500 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Connected load	960 W
AC input voltage	220-240 V
AC input frequency	50 Hz
Annual energy consumption (cooling)	- kWh
Product color	Silver

Weight and Dimensions

Depth	450 mm
Width	500 mm
Height	830 mm
Weight	42000 g
