Sharp CV-P10PR User Manual

GB-16
MAX DENSITY OPERATION
The unit releases max density Plasmacluster ions. By continuously discharging “extra high”
airow for 30 minutes, the unit discharges the ions throughout the room more effectively.
1
Press the MAX DENSITY button during Ion
generator operation.
• The remote control will display " ".
• The red MAXIMUM lamp will light.
TO CANCEL
Press the MAX DENSITY button again.
• The red MAXIMUM lamp will turn off.
NOTES:
• You cannot set the fan speed during MAX DENSITY opera-
tion.
• The MAX DENSITY operation will be automatically can-
celled in 30 minutes, and the unit will return to the original
settings.
• MAX DENSITY operation and REFRESH operation can not
be used together.
USE FOR ION GENERATOR
TO CHANGE AIR FLOW DIRECTION
UP / DOWN AIR FLOW DIRECTION
1
Press the SWING button.
• The horizontal louvers will swing.
2
Press the SWING button again to stop the
desired position.
CAUTION:
Never attempt to adjust the horizontal louvers manually.
• Manual adjustment of the horizontal louvers can cause the
unit to malfunction when the remote control is used for ad-
justment.
LEFT / RIGHT AIR FLOW DIRECTION
Hold the vertical louver as shown in the diagram
and adjust the air ow direction.
1
2
1
01_CV-P10PR_OM_EN.indd 16 14/08/29 16:42

Sharp CV-P10PR Specifications

General

Type	Monobloc mobile air conditioner
Hose length	1.5 m
Noise level	52 dB
Hose diameter	140 mm
Ionic function	Yes
Number of speeds	3
Airflow (high speed)	34.8 m³/h
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1 l/h
Timer duration (maximum)	12 h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling capacity in watts (max)	2500 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Connected load	960 W
AC input voltage	220-240 V
AC input frequency	50 Hz
Annual energy consumption (cooling)	- kWh
Product color	Silver

Weight and Dimensions

Depth	450 mm
Width	500 mm
Height	830 mm
Weight	42000 g
