GB-18
Drain out water within the unit in the following cases.
• When the unit stops operating and the orange TIMER lamp, the green AIR CON lamp
and the red MAXIMUM lamp are blinking, the water tank is full and need to be drained.
• When the unit is not used for a long time.
1
Unplug the power plug and carefully move
the unit to a drain or outside to avoid wa-
ter spilling out into the room.
2
Removethestopcockfromthedrainpipe,
and drain water within the unit.
3
Attach the stopcock securely to the drain-
pipe.
MAIN UNIT OPERATION
1
1
Press the POWER button to start opera-
tion.
• The mode will change as you press the button
within 5 seconds.
• In cool mode, the unit will operate at its last
cooling settings. If the unit has been unplugged
since it was last operated, it will resume opera-
tion in the cooling mode, set at 20˚C. The fan
speed set to AUTO.
TO TURN OFF
Press the POWER button during opera-
tion.
Stopcock
Drainpipe
DRAINAGE
Use this operation when the remote control is not available.
COOL
(The green AIR CON lamp will light)
ION GENERTOR
(The blue ION GENERATOR lamp will light)
OFF
01_CV-P10PR_OM_EN.indd 18 14/08/29 16:42

Sharp CV-P10PR Specifications

General

Type	Monobloc mobile air conditioner
Hose length	1.5 m
Noise level	52 dB
Hose diameter	140 mm
Ionic function	Yes
Number of speeds	3
Airflow (high speed)	34.8 m³/h
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1 l/h
Timer duration (maximum)	12 h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling capacity in watts (max)	2500 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Connected load	960 W
AC input voltage	220-240 V
AC input frequency	50 Hz
Annual energy consumption (cooling)	- kWh
Product color	Silver

Weight and Dimensions

Depth	450 mm
Width	500 mm
Height	830 mm
Weight	42000 g
