UTILITIES
Specifications subject to change without notice: Revision date 10/07 Page 231 of 266
Section – 4: ECR to PC Sending
Step – 1.Connect the ER-A520/ER-A530 to the PC using the previously specified RS-232 cable.
Note: The RS-232 cable from the PC MUST be connected to Channel 2 of the ECR model.
Step –2. At the PC, select the [POSÆPC] button (Fig. 6).
(Fig. 6)
Step – 3. Name the new program data to be saved (Fig. 7).
(Fig. 7)
To Next Page
