EN-19
Parts Name Maintenance Cycle Max Service Life Replacement Model
Plasmacluster Ion
Generating Unit
*
1
Every 6 months or more often if
necessary
19,000 hours
*
2,3
IZ-C90ME
*1: In the following, "Plasmacluster Ion Generating Unit" is abbreviated as "Unit".
*2: The replacement time will be announced by the Unit Replacement lamp.
*3: Designated App notifies when each replacement part should be replaced according to usage.
PLASMACLUSTER ION GENERATING UNIT
(Electrode Section)
REPLACEMENT AND MAINTENANCE CYCLE
MAINTENANCE
1.
Remove the Side Panel and filters from
the left side of the Main Body.
2.
1 Pull out the Unit Holder.
2 Remove the Unit Cleaning Brush.
Unit Cleaning Brush
Unit Holder
3.
Remove dusts from the Electrode
Section.
Unit Cleaning Brush
Electrode
After
cleaning
Before
cleaning
Around the base
Electrode
4.
1 Attach the Unit Cleaning Brush.
2 Insert the Unit Holder.
5.
Install the Side Panel and filters at the
left side of the Main Body.
NOTE
• Do not clean with anything other than the Unit
Cleaning Brush. Doing so could lead to failures
in the Unit.
But if the electrode’s base part is contaminated,
clean it with a slightly wet cotton swab.
• A bent electrode could be cut off and dropped
during the cleaning process, but it will not
change the performance.
• Do not touch the electrode directly. Doing so
could lead to pain/itching.
• Do not transform the Electrode Section. Doing
so can damage it.
• Do not touch the Connection Terminals. Doing
so can damage them.
Connection Terminals
To Next Page
