04/1/28 CX-GD5100V_EN2.fm
19
GX-CD5100W
Radio
■
To recall a memorised station
■
To scan the preset stations
The stations saved in memory can be scanned automatically.
(Preset memory scan)
■
To erase entire preset memory
Setting the FM/MW interval
The International Telecommunication Union (ITU) has established
that member countries should maintain either a 100 kHz or 50 kHz
interval between broadcasting frequencies of FM stations and 10
kHz or 9 kHz for MW stations. The illustration shows the 50/9 kHz
zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
This product is not equipped with a span selector. However, it will be
adjusted to a 50 kHz FM (9 kHz MW) interval when shipped from the
factory.
Before using the unit, be sure to set it to the FM/MW tuning interval
(span) used in your area.
To change the FM/MW tuning interval:
Caution:
●
When the unit is left for a few hours after the span has been
switched and the AC power lead disconnected, the FM span will
be automatically returned to 50 kHz (MW span to 9 kHz). If this
happens, set the span again.
●
When the span is switched, all the memorised stations will be can-
celled.
Press the PRESET ( or ) button for less than 0.5 seconds to se-
lect the desired station.
1 Press the PRESET ( or ) button for more than 0.5 seconds.
The preset number will flash and the programmed stations will be
tuned in sequentially, for 5 seconds each.
2 Press the PRESET ( or ) button again when the desired sta-
tion is located.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Whilst pressing down the REC PAUSE button and the CON-
TINUOUS PLAYBACK
button, press the TUNER (BAND)
button until "TUNER CL" appears.
1 Press the ON/STAND-BY button to turn the power on.
2 Press and hold down the TUNER (BAND) button, for 3 seconds.
3 The display will appear for 2 seconds and the new setting is acti-
vated.
or
To Next Page
