GX-CD5100W
References
Specifications
As part of our policy of continuous improvement, SHARP reserves
the right to make design and specification changes for product im-
provement without prior notice. The performance specification fig-
ures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
■ General
■ Compact disc player
■ Radio
■ Tape recorder
■ Speaker section
Power source AC 110-127/220-240 V, 50/60 Hz
DC IN 12V
DC 15 V , (UM/SUM-1 or R20) x 10
Power consumption 35 W
Output power PMPO: 400 W (Total) (AC operation)
MPO: 36 W (18 W + 18 W) (AC operation,
10% T.H.D)
RMS: 25 W (12.5 W + 12.5 W)
(AC operation,10% T.H.D)
Output terminal Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Input terminals Mixing microphone : 600 ohms
Line input: 350 mV/47 kohms
Dimensions Width: 300 mm (11-4/5")
Height: 252 mm (9-9/10")
Depth: 260 mm (10-1/4")
Weight 4.12 kg (9.08 lbs.) without batteries
Type Compact disc
Signal readout Non-contact, 3-beam semiconductor laser
pickup
Audio channels 2
Filter 8-times over sampling digital filter
D/A converter 1-bit D/A converter
Wow and flutter Unmeasurable (less than 0.001% WRMS)
...
Frequency range FM: 88 - 108 MHz
SW1: 3.2 - 7.3 MHz
SW2: 9.5 - 21.85 MHz
MW: 531 - 1,602 kHz
Frequency response 60 - 8,000 Hz (Normal tape)
Signal/noise ratio 40 dB
Wow and flutter 0.3% (WRMS)
Motor DC 12 V electric governor
Bias system AC bias
Erase system Magnet erase
Type 2-way type
Speakers 13 cm (5-1/8") Woofer
5 cm (2") Tweeter
Maximum input power 25 W
Rated input power 12.5 W
Impedance 8 ohms
Dimensions Width: 232 mm (9-1/8")
Height: 262 mm (10-5/16")
Depth: 235 mm (9-1/4")
Weight 1.80 kg (3.97 lbs.)/each
