Sharp LC-26SH7E User Manual

Introduction
TV (Front view)
B
(Standby/On) indicator
Remote control sensor
TV (Rear view)
AC IN
75Ω
19”
75Ω
AC IN
POWER
button
Volume buttons
MENU button
COMMON
INTERFACE
slot
Composite
(AV IN, AV/LR)
Earphone Output
AC IN
COMMON
INTERFACE
slot
Composite
(AV IN, AV/LR)
S-VIDEO
Service socket
HDMI 3
PC IN (VGA / AUDIO)
COMPONENT (VIDEO and
L/R AUDIO INPUT)
SCART (CVBS Tuner out)
AV VIDEO and L/R Audio Output
HDMI
SERVICE
Socket
Tuner Input
75Ω
SPDIF OUT(Digital audio out)
Tuner Input
SCART 1 (CVBS Tuner out)
SCART 2 (CVBS Monitor out)
AV L/R Audio Output
SERVICE
Socket
PC IN (VGA / AUDIO)
COMPONENT (VIDEO and L/R AUDIO INPUT)
HDMI 1
HDMI 2
75Ω
SPDIF OUT
(Digital audio out)
Earphone Output
P ( )
Programme (Channel)
buttons
3
32”
Power conntector
SERVICE
socket
26”
32”
42”
42”
INPUT SOURCE
button
4

Sharp LC-26SH7E Specifications

General

Comb filter	Digital
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Viewing angle, vertical	150 °
Contrast ratio (dynamic)	8000:1
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
Power requirements	220 - 240V AC, 50 - 60Hz
Headphone connectivity	3.5 mm
SCART ports quantity	2
Digital audio coaxial out	1
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (standby)	0.3 W
Power consumption (typical)	55 W
RMS rated power	10 W
Tuner type	Analog & digital

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
