Sharp LC-32A33T User Manual

LC-32/37A33T
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] CABINET AND MECHANICAL PARTS (LC-32A33T)
1 CCABAC007WJ42 BF N J Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 Not Available - - Badge, SHARP
1-3 HDECQA884WJ4A AN J SP Center Decoration
1-4 HDECQA890WJ4A AD J LED Cover
1-5 HPNLSA215WJ4A AS N J Speaker Sheet
1-6 PSPAHB411WJ4Z AD J Spacer (T-B), x2
1-7 PSPAHB412WJ4Z AC J Spacer (Side), x2
1-8 XEBS930P08000 AA J Screw, x3
1-9 PSPAHB562WJ4Z AB J Spacer, x4
2 CCABBB404WJ41 BD N J Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HINDPD056WJ4A AK N J Terminal Label
2-3 GCOVAC518WJ4Z AE J Hole Cover, x4
2-4 PSPAHB554WJ4Z AC N J Spacer, x2
2-5 PSPAHB555WJ4Z AB N J Spacer, x5
2-6 PSPAHB074WJZZ AB J Spacer, x2
2-7 PSPAHB567WJ4Z AA N J Spacer, x3
2-8 PSPAHB568WJ4Z AB N J Spacer, x2
2-9 PSPAHB574WJ4Z AB N J Spacer
3 R1LK315T3GW30W DA J 32"LCD Panel Module Unit
4 GCOVAA984WJ4A AC J Bass Cover
5 GCOVAC612WJ4A AF J Bottom Cover
6 HINDPD173WJ4A AD N V Model Label
7 JBTN-A718WJ4A AD J Operation Button
8 LANGKB358WJ4W AT J Stand Fix Angle
9 LANGKB399WJ4W AT J Center Angle LR, x2
10 LANGKB470WJ4W AD J LCD Angle-A, x2
11 LANGKB471WJ4W AD J LCD Angle-B, x2
12 LHLDW1033PEZZ AA J Cable Tie, x2
13 LHLDWA143WJKZ AC J Wire Holder
14 PSPAHB379WJ4Z AA J Spacer, x2
15 LHLDZA934WJKZ AB J Wire Holder, x2
16 LHLDZB015WJ4Z AG J
PWB Holder, x2
17 NSFTZ0134CEFW AD J Shaft, x4
18 PSPAHA992WJ4Z AC J Spacer, x2
19 PSPAHB557WJ4Z AB J Spacer
20 PSPAHB562WJ4Z AB J Spacer
21 PSPAZB850WJ4Z AQ J SP Spacer, x2
22 QCNW-H025WJQZ AM N J Connecting Cord (FFC), x2
23 QCNW-G834WJQZ AM J Connecting Cord (PD/LB)
24 QCNW-G835WJQZ AF J Connecting Cord (KM)
25 QCNW-G836WJQZ AM J Connecting Cord (RA)
26 QCNW-G837WJQZ AK J Connecting Cord (SP)
27 RSP-ZA321WJZZ AT N J Speaker Box-L
28 RSP-ZA322WJZZ AT N J Speaker Box-R
29 Not Available - N - No. Label
30 XBPS830P06000 AA J Screw (for HDMI), x2
31 XEBS940P12000 AB J Screw (for CAB A_Angle), x4
32 XEBS940P16000 AB J Screw (for CAB A_B), x6
33 XHPS730P14WS0 AB J Screw (for PWB Holder), x4
34 XHPS830P06WS0 AA J Screw (for Chassis/PWB), x23
35 XHPS830P10WS0 AB J Screw (for CAB B_Panel), x3
36 XEBS930P08000 AA J Screw (for LED PWB)
37 XEBS930P10000 AA J Screw (for AV Jack), x2
38 XHPS730P08WS0 AA J Screw (for Angle_Panel), x2
