LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
4 – 1
LC32LE700E
ServiceManual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Removing of Stand Unit and Rear Cabinet Ass’y.
(32 inch models)
1. Remove the 4 lock screws and detach the Stand Unit .
2. Remove the 1 lock screw , 4 lock screws , 8 lock screws and detach the Rear Cabinet Ass’y.
䎔
䎖
䎘
䎗
䎕
䎶䏗䏄䏑䏇䎃䎸䏑䏌䏗
䎵䏈䏄䏕䎃䎦䏄䏅䏌䏑䏈䏗䎃䎤䏖䏖䎊䏜
