Sharp LC-32LE700E User Manual

PARTS GUIDE
No. S89B4LC32L700
MODELS
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
LC-32LE700E/RU/S, LC-32LU700E/S
LC-32LX700E/RU
LC-40LE700E/RU/S, LC-40LU700E/S
LC-40LX700E/RU
LC-46LE700E/RU/S, LC-46LU700E/S
LC-46LX700E/RU
LC-52LE700E/RU/S
LCD COLOUR TELEVISION
Note:
The reference numbers on
the PWB are arranged in
alphabetical order.
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] DUNTKE306FM01 (MAIN Unit)
[4] DUNTKE266FM18 (KEY Unit)
[5] DUNTKF308FM02 (R/C, LED Unit)
[6] DUNTKF314FM02 (ICON Unit)
[7] CABINET AND MECHANICAL
PARTS (LC-32LE/LU/LX700)
[8] LCD PANEL MODULE UNIT (LC-
32LE/LU/LX700)
[9] CABINET AND MECHANICAL
PARTS (LC-40LE/LU/LX700)
[10] LCD PANEL MODULE UNIT (LC-
40LE/LU/LX700)
[11] CABINET AND MECHANICAL
PARTS (LC-46LE/LU/LX700)
[12] LCD PANEL MODULE UNIT (LC-
46LE/LU/LX700)
[13] CABINET AND MECHANICAL
PARTS (LC-52LE700)
[14] LCD PANEL MODULE UNIT (LC-
52LE700)
[15] SUPPLIED ACCESSORIES
[16] PACKING PARTS (NOT
REPLACEMENT ITEM) (LC-32/
40LE/LU/LX700)
[17] PACKING PARTS (NOT
REPLACEMENT ITEM) (LC-46LE/
LU/LX700, LC-52LE700)
[18] SERVICE JIGS (USE FOR
SERVICING)

Sharp LC-32LE700E Specifications

General

Display diagonal	32 \
Native aspect ratio	16:9
Native refresh rate	100 Hz
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	Yes
HDMI ports quantity	4
USB 2.0 ports quantity	1

Weight and Dimensions

Depth (without stand)	92 mm
Width (without stand)	767 mm
Height (without stand)	502 mm
Weight (without stand)	13500 g
