Sharp LC-32LE700E User Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE306FM01 CD N P MAIN Unit
N DUNTKE266FM18 AR N P KEY Unit
N DUNTKF308FM02 AL N P R/C, LED Unit
N DUNTKF314FM02 AL N P ICON Unit
!
N RUNTKA619WJQZ BS N P POWER Unit (for 32 inch model)
!
N RUNTKA609WJQZ BW N P POWER Unit (for 40 inch model)
!
N RUNTKA611WJQZ BZ P POWER Unit (for 46/52 inch model)
N RUNTK4225TPZE BR N P LCD Control Unit
N RUNTKA595WJ01 AX P LED5-PWB1 Unit (for 32/40/46 inch model)
N RUNTKA595WJ02 AX P LED5-PWB2 Unit (for 32/40/46 inch model)
N RUNTKA596WJ01 AY P LED6-PWB1 Unit (for 40/46/52 inch model)
N RUNTKA596WJ02 AY P LED6-PWB2 Unit (for 40/46/52 inch model)
N RUNTKA598WJ01 P LED8-PWB1 Unit (for 32/46/52 inch model)
N RUNTKA598WJ02 P LED8-PWB2 Unit (for 32/46/52 inch model)
[2] LCD PANEL
N DLCUCA001FM03 N P 32"LCD Panel Module Unit (for 32 inch model)
N DLCUCA002FM03 N P 40"LCD Panel Module Unit (for 40 inch model)
N DLCUCA003FM03 N P 46"LCD Panel Module Unit (for 46 inch model)
N DLCUCA004FM03 N P 52"LCD Panel Module Unit (for 52 inch model)
[3] DUNTKE306FM01 (MAIN Unit)
C501 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C502 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C503 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C507 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C508 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C510 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C511 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C519 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C520 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C521 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C522 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C523 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C524 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C525 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C526 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C527 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C528 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C529 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C530 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C531 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C532 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C533 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C534 RC-KZA510WJPZY AB J Capacitor
C535 RC-KZA510WJPZY AB J Capacitor
C536 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C537 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C538 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C539 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C540 RC-KZA510WJPZY AB J Capacitor
C541 RC-KZA510WJPZY AB J Capacitor
C542 RC-KZA510WJPZY AB J Capacitor
C543 RC-KZA510WJPZY AB J Capacitor
C544 RC-KZA510WJPZY AB J Capacitor
C545 RC-KZA510WJPZY AB J
Capacitor
C546 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C547 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C548 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C549 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C550 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C551 VCERMZ1CN477MY AE J Capacitor 470 16V (AL)
C553 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C554 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C555 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C556 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C557 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C558 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C559 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C560 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C562 RC-KZA510WJPZY AB J Capacitor
C564 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C565 VCKYCZ1EB472KY AB J Capacitor 4700p 25V Ceramic
C566 VCKYCZ1EB472KY AB J Capacitor 4700p 25V Ceramic
C567 VCEASY1EN107MY AC J Capacitor 100 25V Electrolytic
C568 VCEASY1EN107MY AC J Capacitor 100 25V Electrolytic
C569 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C570 RC-KZA067WJZZY AB J Capacitor
C571 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C572 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C573 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C575 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C576 RC-KZA067WJZZY AB J Capacitor
C577 RC-KZA616WJQZY AB J Capacitor
C578 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic

Sharp LC-32LE700E Specifications

General

Display diagonal	32 \
Native aspect ratio	16:9
Native refresh rate	100 Hz
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	Yes
HDMI ports quantity	4
USB 2.0 ports quantity	1

Weight and Dimensions

Depth (without stand)	92 mm
Width (without stand)	767 mm
Height (without stand)	502 mm
Weight (without stand)	13500 g
