Sharp LC-32LE700E User Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
6 – 17
<During external connection> No picture on the monitor (3)
No picture from EXT1 appears on EXT2-connected monitor.
Is CVBS signal output into pin (19) of EXT2 (SC502)? YES Check the setting of an external input device that connects with
EXT2.
NO
Is CVBS signal input to pin(1) of IC508 from pin(AJ24/
CVBS_MONI_OUT) of IC3302
(Digital AV decode & Main CPU)?
YES Check the IC508 and their peripheral circuits.
NO
Is CVBS signal sent to pin(AG29/SC1_CVBS/Y) of IC3302
(Digital AV decode & Main CPU) from EXT1(SC503)?
YES Check the IC3302 and their peripheral circuits.
NO
Is CVBS signal sent to pin (20) of EXT1(SC503)? YES Check the line between EXT1(SC503) and IC3302.
NO
Check the setting of an external input device that connects with
EXT1.
<During external connection> No picture on the monitor (4)
No picture from EXT8 appears on EXT2- connected monitor.
Is CVBS signal output into pin(19) of EXT2 (SC502)? YES Check the setting of an external input device that connects with
EXT2.
NO
Is CVBS signal input to pin(1) of IC508 from pin(AJ24/
CVBS_MONI_OUT) of IC3302
(Digital AV decode & Main CPU)?
YES Check the IC508 and their peripheral circuits.
NO
Is CVBS signal input to pin (AE29/CVBS__IN) of IC3302 from
J505?
YES Check the IC3302 and their peripheral circuits.
NO
Is CVBS signal sent to pin (6) of EXT8(J505)? YES Check the line between EXT8(J505) and IC3302.
NO
Is V3_PLUG detection signal input to pin (AJ11/CVBS/PLUG) of
IC3302 from pin(7) of EXT8 (J505)?
YES Check the line between EXT8(J505) and IC3302.
NO
Check the setting of an external input device that connects with
EXT8.

Sharp LC-32LE700E Specifications

General

Display diagonal	32 \
Native aspect ratio	16:9
Native refresh rate	100 Hz
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	Yes
HDMI ports quantity	4
USB 2.0 ports quantity	1

Weight and Dimensions

Depth (without stand)	92 mm
Width (without stand)	767 mm
Height (without stand)	502 mm
Weight (without stand)	13500 g
