LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
7 – 2
IC1504 VHiSiI9287+-1Q HDMI_Port _Processor The SiI9287 HDMI port processor is the second generation of HDMI devices that
support revision 1.3 of the HDMI specification. The main feature is as follows.
1) 4-input, 1-output HDMI port processor.
2) Integrated TMDS receiver and transmitter cores capable of receiving and trans-
mitting at 2.25Gbps.
3) Supports video resolutions up to 1080p, 60Hz, 12bit or 720p/1080i, 120Hz,12bit.
4) Receiver fully comply with DVI1.0, HDCP1.1 and HDMI1.3 specifications.
IC1106 VHiSTV0297E-1Q COFDM The STV0297E’s demodulator is a complete QAM (quadrature amplitude modula-
tion) demodulation and FEC (forward error correction) solution that performs IF to
transport
stream block processing of QAM signals. It is intended for the digital transmission
of compressed television, sound, and data services over cable.
IC1103 VHiTCR5SB25-1Y 1CH-SW-REG
REG-2.5V
The TCR5SB25 is CMOS general-purpose single-output voltage regulators with an
on/off control input, featuring low dropout voltage and low quiescent bias current.
The output current is possible up to 200mA or less. In this model, it generate
CPU2.5V.
IC9609 VHiTCR5SB33-1Y 1CH-SW-REG
Reg 3.3V
The TCR5SB33 is CMOS general-purpose single-output voltage regulators with an
on/off control input, featuring low dropout voltage and low quiescent bias current.
The output current is possible up to 200mA or less. In this model, it generate
Bu3.3V.
IC2701 VHiYDA148QZ-1Y A-AMP This IC is a digital audio power amplifier. It is mounted by 32QFN small package
with 15W or less stereo. it drives by 10W in 26, and 32 types.
[POWER/INVERTER UNIT]
IC7102 TNY274PN
BU5V
SW-REG-CTL
This IC is IC for the switching regulator with Enhanced Flexibility and Extended
Power Range
In this model, non-reg BU5V power supply is generated.
IC7101 UCC28061
UR13V
P-FACTOR
This IC is IC that improves Power-Factor in 13V_Regulator circuit of 46 type power
supply circuit.
The protection functions such as UVLO, Brounout, OVP and AOC are built into in
this IC.
IC7200 NCP1606B
UR13V
P-FACTOR
This IC is IC that improves Power-Factor in 13V_Regulator circuit of 40 type power
supply circuit.
The protection functions such as UVLO, Brounout, OVP and AOC are built into in
this IC.
IC7104 SSC9502S
UR13V
SW-REG-CTL
This IC is switching power supply IC of a monolithic type.
In this model, non-reg UR13V power supply is generated.
IC7505 FA5573
VLCD
LOW-STANDBY
This IC is IC for the low standby power requirement type switching power supply
control.
In this model, backlight LED power supply (VLED=187/209V) is generated.
IC7101 VIPER17
BU5V
SW-REG-CTL
This IC is switching power supply IC of the off-line converter type with a PWM con-
trol.
In this model, non-reg BU5V power supply is generated.
IC7001 L6562A
UR13V
P-FACTOR
This IC is IC that improves Power-Factor in 13V_Regulator circuit of 32 type power
supply circuit.
The protection functions such as UVLO, Brounout, OVP and AOC are built into in
this IC.
IC7002 FA5538
UR13V
SW-REG-CTL
This IC is switching-power-supply control IC of the current mode system where
power MOSFET drives directly. In this model, UR13V (32 types) is generated.
IC7251 FA5511
VLCD
SW-REG-CTL
This IC is IC for the PWM type switching power supply control.
In this model, backlight LED power supply (VLED=144V) is generated.
Ref No. Name Part Code Description
