LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
7 – 19
105 CI_CLE I NAND Flash Command Latch enable. PACLE_
117 CI_OEB I NAND Flash Output enable. XERE_
CLK/Crystal
109 XTALO O Crystal output. XTAL_O
110 XTALI I Crystal input. XTAL_I
Transport stream (TS)
6 TOCLK I Transport stream 1 input clock. TS_CPUOUT_CLK
7 TOSYNC I Transport stream 1 input sync. TS_CPUOUT_SYNC
8 TOVALID I Transport stream 1 input valid. TS_CPUOUT_VAL
9 TODATA0 I Transport stream 1 input data bit 0. TS_CPUOUT_DO
11 TODATA1 I Transport stream 1 input data bit 1.
Transport stream 2 input clock.
open
12 TODATA2 I Transport stream 1 input data bit 2.
Transport stream 2 input sync.
open
13 TODATA3 I Transport stream 1 input data bit 3.
Transport stream 2 input valid.
open
14 TODATA4 I Transport stream 1 input data bit 4.
Transport stream 2 input data.
open
16 TODATA5 I Transport stream 1 input data bit 5. open
17 TODATA6 I Transport stream 1 input data bit 6. open
18 TODATA7 I Transport stream 1 input data bit 7. open
123 TS_CKO O Transport stream output clock. TS_CPUIN_CLK
125 TS_SYNCO O Transport stream output sync. TS_CPUIN_SYNC
122 TS_VALIDO O Transport stream output valid. TS_CPUIN_VAL
124 TS_DATAO O Transport stream output data. TS_CPUIN_DO
General Purpose Input and Output (GPIO)
1 GPIO0 I/O General purpose I/O bit 0. (Resister-Ground) R-G
2 GPIO1 I/O General purpose I/O bit 1. (Resister-Ground) R-G
3 GPIO2 I General purpose I/O bit 2. (Head Phone Plug) HP_PLUG
4 GPIO3 O General purpose I/O bit 3. (Amp Standby) AMP_STBY
19 GPIO4 I/O General purpose I/O bit 4. open
20 GPIO5 O General purpose I/O bit 5. (Antena_5V_SW) ANT_5V_SW
21 GPIO6 I/O General purpose I/O bit 6. open
91 GPIO7 I/O General purpose I/O bit 7. open
92 GPIO8 I/O General purpose I/O bit 8. open
93 GPIO9 O General purpose I/O bit 9. (Common Interface VCC Enable) CI_VCCEN
118 GPIO10 O General purpose I/O bit 10. (Panel I2C Enable) PNL_I2C_EN
119 GPIO11 O General purpose I/O bit 11. (Panel Write Protect) PNL_WP
120 GPIO12 I General purpose I/O bit 12. (232C_Eable) 232C_EN
127 GPIO13 O General purpose I/O bit 13. (ATV_Power_SW) ATV_POW_SW
128 GPIO14 I General purpose I/O bit 14. (Interrupt enable _SW) IREM_SW
PCMCIA/CI
83 D0 I/O PCMCIA data bit 0. C_D0
85 D1 I/O PCMCIA data bit 1. C_D1
87 D2 I/O PCMCIA data bit 2. C_D2
24 D3 I/O PCMCIA data bit 3. C_D3
26 D4 I/O PCMCIA data bit 4. C_D4
28 D5 I/O PCMCIA data bit 5. C_D5
30 D6 I/O PCMCIA data bit 6. C_D6
32 D7 I/O PCMCIA data bit 7. C_D7
81 D8 I/O PCMCIA data bit 8. TS_CIOUT_D0
84 D9 I/O PCMCIA data bit 9. TS_CIOUT_D1
86 D10 I/O PCMCIA data bit 10. TS_CIOUT_D2
25 D11 I/O PCMCIA data bit 11. TS_CIOUT_D3
27 D12 I/O PCMCIA data bit 12. TS_CIOUT_D4
29 D13 I/O PCMCIA data bit 13. TS_CIOUT_D5
31 D14 I/O PCMCIA data bit 14. TS_CIOUT_D6
34 D15 I/O PCMCIA data bit 15. TS_CIOUT_D7
80 A0 O PCMCIA address bit 0. CI_A0
78 A1 O PCMCIA address bit 1. CI_A1
75 A2 O PCMCIA address bit 2. CI_A2
73 A3 O PCMCIA address bit 3. CI_A3
71 A4 O PCMCIA address bit 4. CI_A4
69 A5 O PCMCIA address bit 5. CI_A5
66 A6 O PCMCIA address bit 6. CI_A6
Pin No. Pin Name I/O Pin Function Sheet Name
