2.17. IC2001 (VHiS80927NM-1Y)
2.17.1 Block Diagram
2.17.2 Pin Connections and short description
Pin No. Pin Name I/O Pin Function
1 OUT O Voltage detection output terminal (RESET detecting voltage)
2 VDD - Voltage input terminal
3 VSS - Ground terminal
4 NC - No connection (It is an opening electrically.)
5 CD I External capacitor connection terminal for delay
S
D
G
-
VSS
OUT
CIRCUIT
VIN
2
DELAY
RESET
OUT
VDD
CD
S80928NM 2.8V
+
VREF
3
5
VOLTAGE-DETECTOR
1
S80927NM 2.7V
S80920NM 2.0V
S80944NM 4.4V
