LC-46LE925E
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB UNIT
NOTE: (*1) Replace MAIN Unit (DKEYDF655FM01) in case of IC8401 or IC3302 failure.
(*2) TOUCH SENSOR KEY Unit (RUNTKA761WJQZ) reuse will be impossible, once it is stuck on front cabinet and exfoliates.
Therefore, please exchange of a TOUCH SENSOR KEY Unit in the case of front cabinet exchange.
OTHER UNIT
IC FOR EXCLUSIVE USE OF THE SERVICE
SERVICE JIGS
Ref No. Parts Code Description
N DKEYDF655FM01 MAIN Unit (*1)
N DUNTKF494FM02 R/C, LED Unit
N DUNTKF638FM02 ICON Unit
N DUNTKF493FM04 LOGO Unit
N RUNTKA761WJQZ TOUCH SENSOR KEY Unit (*2)
N RDENCA398WJQZ POWER Unit
N RUNTKA740WJQZ HDMI CONVERTER Unit
N RUNTKA741WJQZ IR TRANSMITTER Unit
N RUNTK4568TPZJ LCD CONTROL Unit (LC-46LE925E)
N RUNTK4568TPZS LCD CONTROL Unit (LC-60LE925E)
N RUNTK4434TPZA LED DRIVER Unit (LC-46LE925E)
N RUNTK4433TPZB LED DRIVER Unit (LC-60LE925E)
Ref No. Parts Code Description
N R1LK460D3LWF0Y 46” LCD Panel Module Unit (LC-46LE925E)
N R1LK600D3LW5AZ 60” LCD Panel Module Unit (LC-60LE925E)
Ref No. Parts Code Description Q’ty
IC509 RH-iXD212WJQZS IC R1EX24002ASAS0A (PC EDID) 1
IC2002 RH-iXC786WJNYQ IC R5F364A6NFB (Monitor MICON) 1
Ref No. Parts Code Description Q’ty
N QCNW-G616WJQZ Main Unit to LCD Control Unit/HDMI Converter Unit (LW/HN) 2
N QCNW-H184WJQZ Main Unit to Power Unit (PD) 1
N QCNW-G625WJQZ LCD Control Unit to Power Unit (PL) 1
N QCNW-L220WJQZ LED Driver Unit to Power Unit (LA) 1
N QCNW-H185WJQZ Main Unit to LED Drive Unit (LB) 1
N QCNW-L222WJQZ Main Unit to R/C, LED Unit (RA) 1
N QCNW-K595WJQZ Main Unit to Speaker (SP) 1
N QCNW-K597WJQZ Main Unit to Woofer (SB) 1
N QCNW-L223WJQZ Main Unit to Icon/Logo Unit (RL) 1
N QCNW-L219WJQZ HDMI Converter Unit to Power Unit (PN) 1
N QCNW-L221WJQZ Main Unit to IR Transmitter Unit (IR) 1

Sharp LC-46LE925E Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	46 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	100 Hz
LED backlighting type	Edge-LED
Viewing angle, horizontal	176 °
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	-
HDMI ports quantity	4
DVI-D ports quantity	0
Common interface (CI)	No
USB 2.0 ports quantity	1
Common interface Plus (CI+)	Yes
Consumer Electronics Control (CEC)	Aquos Link
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.2 W
Power consumption (typical)	95.1 W
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T

Weight and Dimensions

Depth (with stand)	340 mm
Height (with stand)	785 mm
Weight (with stand)	45000 g
Depth (without stand)	39 mm
Width (without stand)	1127 mm
Height (without stand)	734 mm
