LC-46/60LE925E
8 – 1
LC-46LE925E
Service Manual
CHAPTER 8. MAJOR IC INFORMATIONS
[1] MAJOR IC INFORMATIONS
REF NO Name Part Code Description
[MAIN UNIT]
IC8401 RH-iXD047WJQZQ Flash This IC is 1024Mbit NAND flash memory.
This IC stores the software data that processes the system of TV such as the graphic process-
ing, the LCD controls, and backlights etc.
IC3302 RH-iXC951WJN1Q Main CPU This IC is Video Processor & MAIN CPU.
In this IC, the decode processing and the video signal processing are done.
Moreover, OSD is generated here and added to a picture signal.
IC2002 RH-iXC786WJQZQ
for service
(RH-iXC786WJNYQ)
UCOM The monitor microprocessor is intended to communicate with the main CPU and to operate the
system.
It also controls power of the entire system.
IC3501
IC3502
RH-iXC754WJQZQ DDR This IC is 1GB DDR2 SDRAM.
This IC operates as a memory of IC3302 (Video Processor).
IC509 VHiR24002AS-1Y
for service
(RH-IXD212WJQZS)
1K bit
E2PROM
This IC is a 1Kbit-2-wire (I2C bus type) serial EEPROM that can be programmed electrically.
The EEPROM chip stores the EDID data of PC input.
This data is controlled through I2C signals.
IC8455 VHiR24064AS-1Y 64K bit
E2PROM
The BR24S64W is a 64Kbit-2-wire (I2C bus type) serial EEPROM that can be programmed
electrically.
This IC stores the menu data and the adjustment value data of adjustment process mode etc.
The data is given out by commands from the main microprocessor.
IC506 VHiM3221EiP-1Y RS232C-
DRIVER
The MAX3221E is a single driver, single receiver RS-232 solution operating from a single Vcc
supply. The RS-232 pins provide IEC G1000-4-2 ESD Protection.
The device meets the requirements of TIA/EIA-232-F and provides the electrical interface
between an asynchronous communication controller and the serial-port connector. The charge
pump and four small external capacitors allow operation from a single 3V to 5.5V supply.
IC4405 VHiMT8295AE-1Q CI controller This is a control IC for PCMCIA cards. This controls information on IC cards inserted into the
PCMCIA card slot (SC4401) or information on software version upgrade cards saved on flash
memories to transfer the data to CPUs and memories.
IC2004 VHiR24002AS-1Y 2K bit
E2PROM
This is a 2Kbit-2-wire (I2C bus type) serial EEPROM that can be programmed electrically.
This IC stores the menu data and the adjustment value data of adjustment process mode etc.
The data is given out by commands from the main microprocessor.
IC1504 VHiSii9387+-1Q HDMI_Port_
Processor
The Sii9387 HDMI port processor is the second generation of HDMI devices that support revi-
sion 1.4 of the HDMI specification.
The main feature is as follows.
1) 5-input, 1-output HDMI port processor.
2) Audio Return Channel that allows an S/PDIF uplink from HDMI sink device to an HDMI
source available in one reciver port
3) Integrated TMDS receiver and transmitter cores capable of receiving and transmitting at
2.25Gbps.
4) Supports video resolutions up to 1080p, 60Hz, 12bit or 720p/1080i, 120Hz,12bit.
5) Receiver fully comply with DVI1.0, HDCP and several optional 3D formats described in the
HDMI1.4 specifications.
IC1106 VHiSTV0297E-1Q QAM
Demodulator
The STV0297E’s demodulator is a complete QAM (quadrature amplitude modulation) demodu-
lation and FEC (forward error correction) solution that performs IF to transport stream block
processing of QAM signals. It is intended for the digital transmission of compressed television,
sound, and data services over cable.
IC9501 VHiKSZ8041T-1Y Ethernet Bus
Interface
This IC is a single supply 10Base-T/100Base-TX Physical Layer Transceiver, which provides
MII/RMII/SMII interfaces to transmit and receive data.
IC2701 VHiYSS951VZ-1Y Sound
processor
This IC is the Sound processing LSI with built-in two DSP (MDSP/SDSP) and FM (frequency
modulation) oscillators.
This IC process sound signal and sent it to AMP for Speaker and Woofer.
IC2702
IC2703
VHiYDA164QZ-1Y Audio-AMP This IC is digital audio power amplifier with digital audio interface.
The power-supply voltage is corresponded to A.8V~18V and the maximum output is 20Wx2ch.
IC1301 RH-iXC563WJQZY LNB supply
and control
It is IC for amplifying the feeble electric wave sent from satellite broadcasting on the level which
can treat a decoder, and changing and processing signal.
IC2401 RH-iXD182WJQZQ FPGA This IC is Field Programmable Gate Array to change LVDS format.
IC2403 RH-iXD183WJQZQ Config ROM This IC is serial Flash memory (16Mbit) provides a shorage solution for systems with limited
space, pins and power.
IC2402 VHiLVD1023B1EQ LVDS
transmitter
This IC is LVDS transmitter that is designed to support Single Link transmission.
This converts 67bits of CMOS/TTL data into LVDS data stream.
In Dual Link, the transmit clock frequency of 136MHz, 67bits of RGM data are transmitted at an
effective rate of 945Mbps per LVDS channel.
To Next Page
