Sharp LC-46LE925E User Manual

PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-46/60LE925E
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES (LC-46LE925E)
[2] PRINTED WIRING BOARD
ASSEMBLIES (LC-60LE925E)
[3] LCD PANEL MODULE
[4] CABINET PARTS (LC-46LE925E)
[5] CABINET PARTS (LC-60LE925E)
[6] SUPPLIED ACCESSORIES
[7] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-46LE925E)
[8] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-60LE925E)
[9] SERVICE JIGS
(USE FOR SERVICING)
CONTENTS
No. S90M146LE925E
LCD COLOUR TELEVISION
LC-46LE925E
LC-60LE925E
MODELS

Sharp LC-46LE925E Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	46 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	100 Hz
LED backlighting type	Edge-LED
Viewing angle, horizontal	176 °
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	-
HDMI ports quantity	4
DVI-D ports quantity	0
Common interface (CI)	No
USB 2.0 ports quantity	1
Common interface Plus (CI+)	Yes
Consumer Electronics Control (CEC)	Aquos Link
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.2 W
Power consumption (typical)	95.1 W
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T

Weight and Dimensions

Depth (with stand)	340 mm
Height (with stand)	785 mm
Weight (with stand)	45000 g
Depth (without stand)	39 mm
Width (without stand)	1127 mm
Height (without stand)	734 mm
