Sharp LC-46LE925E User Manual

LC-46/60LE925E
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES (LC-46LE925E)
N DKEYDF655FM01 N P MAIN Unit
N DUNTKF494FM02 AP P R/C, LED Unit
N DUNTKF638FM02 P ICON Unit
N DUNTKF493FM04 AQ P LOGO Unit
N RUNTKA761WJQZ P TOUCH SENSOR KEY Unit
N RDENCA398WJQZ BV N P POWER Unit
N RUNTKA740WJQZ BV N P HDMI CONVERTER Unit
N RUNTKA741WJQZ AZ N P IR TRANSMITTER Unit
N RUNTK4568TPZJ CL N P LCD CONTROL Unit
N RUNTK4434TPZA BV N P LED DRIVER Unit
[2] PRINTED WIRING BOARD ASSEMBLIES (LC-60LE925E)
N DKEYDF655FM01 N S MAIN Unit
N DUNTKF494FM02 AP P R/C, LED Unit
N DUNTKF638FM02 P ICON Unit
N DUNTKF493FM04 AQ P LOGO Unit
N RUNTKA761WJQZ N S TOUCH SENSOR KEY Unit
N RDENCA398WJQZ BV N S POWER Unit
N RUNTKA740WJQZ BV N P HDMI CONVERTER Unit
N RUNTKA741WJQZ AZ N P IR TRANSMITTER Unit
N RUNTK4568TPZS N S LCD CONTROL Unit
N RUNTK4433TPZB N S LED DRIVER Unit
[3] LCD PANEL MODULE
N R1LK460D3LWF0Y EF N P 46" LCD Panel Module Unit (LC-46LE925E)
N R1LK600D3LW5AZ N S 60" LCD Panel Module Unit (LC-60LE925E)

Sharp LC-46LE925E Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	46 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	100 Hz
LED backlighting type	Edge-LED
Viewing angle, horizontal	176 °
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	-
HDMI ports quantity	4
DVI-D ports quantity	0
Common interface (CI)	No
USB 2.0 ports quantity	1
Common interface Plus (CI+)	Yes
Consumer Electronics Control (CEC)	Aquos Link
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.2 W
Power consumption (typical)	95.1 W
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T

Weight and Dimensions

Depth (with stand)	340 mm
Height (with stand)	785 mm
Weight (with stand)	45000 g
Depth (without stand)	39 mm
Width (without stand)	1127 mm
Height (without stand)	734 mm
